Guidance and manufacturer's declaration – electromagnetic
immunity – for all EQUIPMENT and SYSTEMS
Guidance and manufacturer´s declaration – electromagnetic immunity
The Model Grid Pad 15 are intended for use in the electromagnetic environment specified below. The customer or the user of the
Model Grid Pad 15 should assure that it is used in such an environment.
Immunity test
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrostatic
transient / burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
NOTE: UT is the a. c. mains voltage prior to application of the test level.
IEC 60601
test level
± 8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
± 2 kV for power
supply lines
100 kHz repetition frequency
± 1 kV for input/output
lines
± 0.5 kV, ± 1 kV differential
mode
line-line
0 % UT
(100 % dip in UT )
for 0.5 cycle at 0°, 45°,
90°, 135°,180°, 225°, 270°,
and 315°
0 % UT
(100 % dip in UT )
for 1 cycle at 0°
70 % UT
(30 % dip in UT )
for 25/30 cycles at 0°
0 % UT
(100 % dip in UT )
for 250/300 cycle at 0°
30 A/m, 50/60Hz
Compliance level
± 8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15
± 2 kV for power
supply lines
100 kHz repetition frequency
± 0.5 kV, ± 1 kV differential
mode
line-line
0 % UT
(100 % dip in UT )
for 0.5 cycle at 0°, 45°,
90°, 135°,180°, 225°, 270°,
and 315°
0 % UT
(100 % dip in UT )
for 1 cycle at 0°
70 % UT
(30 % dip in UT )
for 25/30 cycles at 0°
0 % UT
(100 % dip in UT )
for 250/300 cycle at 0°
30 A/m, 50/60Hz
Electromagnetic environment -
guidance
Floors should be wood, concrete or
ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30 %.
Mains power quality should be that
of a typical commercial or hospital
environment.
Mains power quality should be that
of a typical commercial or hospital
environment.
Mains power quality should be
that of a typical commercial
or hospital environment. If
the user of the models Grid
Pad 15 product name requires
continued operation during
power mains interruptions, it is
recommended that the models
Grid Pad 15 be powered from
an interruptible power supply
or a battery.
Power frequency magnetic fields
should be at levels characteristic of
a typical location in a typical com-
mercial or hospital environment.
