Acksys AirBox WIFI V2 Guide D'installation Rapide page 35

WiFi2 / Dual-band 11ac wave 1 3T/3R
Output Tx power
(radio card output)
Values are given by the radio card manufacturer at ±2dB.
They must be subtracted by 2dB because of RF losses between radio card connector and antenna
connector. The values are given for 1 chain. Aggregate power is calculated by adding 3 dB for 2 chains
and 4.8 dB for 3 chains.
Rx sensitivity (radio
card input)
Values are given by the radio card manufacturer with a ±2dB tolerance.
Add 2 dB to get the value on the antenna connector.
802.11b/g
802.11a
802.11gn HT20
802.11gn HT40
802.11an HT20
802.11an HT40
802.11ac HT20
802.11ac HT40
802.11ac HT80
802.11b
802.11b/g
802.11a
802.11gn HT20
802.11gn HT40
802.11an HT20
802.11an HT40
802.11ac HT20
802.11ac HT40
802.11ac HT80
- -
17
1 RF chain
19 dBm @ 6M
15 dBm @ 54M
18 dBm @ 6M
15 dBm @ 54M
19 dBm @ MCS 0
13 dBm @ MCS 7
18 dBm @ MCS 0
13 dBm @ MCS 7
18 dBm @ MCS 0
13 dBm @ MCS 7
18 dBm @ MCS 0
12 dBm @ MCS 7
18 dBm @ MCS 0
12 dBm @ MCS 9
18 dBm @ MCS 0
11 dBm @ MCS 9
18 dBm @ MCS 0
10 dBm @ MCS 9
Non disponible
-94 dBm @6M
-80 dBm @54M
-96 dBm @6M
-84 dBm @54M
-94 dBm @MCS 0
-77 dBm @MCS 7
-93 dBm @MCS 0
-75 dBm @MCS 7
-95 dBm @MCS 0
-77 dBm @MCS 7
-92 dBm @MCS 0
-77 dBm @MCS 7
-94 dBm @MCS 0
-70 dBm @MCS 9
-91 dBm @MCS 0
-65 dBm @MCS 9
-90 dBm @MCS 0
-61 dBm @MCS 9
