9-48VDC connector (Power supply)
5-way terminal block
connector
RJ45 connectors
Digital I/O connector (Digital inputs/outputs)
8-way terminal block
connector
CONNECTORS
Signal name
Power 1
Power 2
EARTH
LAN connectors (Ethernet)
LAN1 and LAN2 are two Ethernet ports.
These ports support the Auto-negotiation
function.
They
transmission speed (10 Base-T, 100 Base-
Tx or 1000 Base-T Half/Full Duplex).
It enables to the device to coexist in the
network by mitigating the risks of network
disruption
technologies.
LAN2 has a PoE Powered Device, built in
interface, 802.3 af compliant.
Signal name
OUT1
OUT2
IN1
IN2
-
-
8
VIN1-
VIN1+
VIN2-
VIN2+
can
automatically
arising
from
V
out1
GND
V
out2
GND
V
in1
GND
V
in2
GND
Pin
1
2
3
4
5
select
the
incompatible
Pin
1
5
2
6
3
7
4
8
