Ethernet interface
Number of ports
Type of ports
Connectors
Cables
Digital inputs
Number of DIO
Type
Tension max
Isolation
Connector
Digital outputs (Alarm contact)
Number of DIO
Type
Max voltage
Max load current
ON-Resistance
Isolation
Connector
Wi-Fi interfaces
Number of interfaces
WiFi or WiFi1
WiFi2
Radio mode
Modulation rates
Frequency range for
802.11a/n/ac
Frequency range for
802.11b/g/n
Antenna sockets
2 (LAN1, LAN2), LAN2 with PoE 802.3af
Auto MDI/MDI-X
10 BASE T/100 BASE Tx/1000 BASE T
with automatic 802.3u negotiation
(10/100/1000 Mbps)
RJ45
Ethernet CAT5e UTP, 2x RJ45
connector (straight cable T568B)
2 (IN1, IN2)
Opto-isolated
24VDC, protected against over-voltage
1500V
8-ways terminal block connector
2 (OUT1, OUT2)
Solid state relay 1 form A (normally open)
60VDC, not polarized, protected against
transient over-voltage
80mA
25 ohms typ., 35 ohms max
1500V
8-ways terminal block Connector
1 for AirBox/10 ou /14 (WiFi)
2 for AirBox/12 (WiFi1, WiFi2)
802.11n 2T/2R (modes a & g, 300 Mbps max.)
802.11ac wave 1 3T/3R (modes a & g, 1.3 Gbps
max.)
Supports for IEEE 802.11a/h, 802.11b, 802.11g,
802.11n and 802.11ac
802.11ac 3T/3R: up to 1.3 Gbps
802.11n 2T/2R: up to 300 Mbps
802.11a/h: 6 to 54 Mbps
802.11b: 1 to 11 Mbps
802.11g: 1 to 54 Mbps
5 GHz; 5.150 to 5.850 GHz
2.4 GHz; 2.412 to 2.484 GHz
2 RP-SMA female for AirBox/10
5 RP-SMA female for AirBox/12
- -
