ENGLISH
MACHINE STRUCTURE (Continues)
41. Recovery water tank cover (open)
42. Recovery water tank cover gasket
43. Brush/pad support
44. Recovery tank compartment
45. Solution tank fi ller neck
46. Vacuum grid with automatic shut-off fl oat
47. Recovery water drain hole
48. Vacuum system motor
49. Brush/pad motor
50. Batteries
51. Battery installation diagram
52. Deck with brush/pad-holder coupling pin
53. Machine speed adjustment screw
54. Brush
55. Pad-holder
56. Pad
57. Screw
58. Brush/pad-holder engagement rotation direction
59. Foam fi lter
51
57
6
INSTRUCTIONS FOR USE
53
909 5853 000(4)2009-11
47
52
50
54
48
49
58
Micromatic™ M17B
41
42
46
44
45
43
59
55
56
S310235
