Enabling ACT™
Monsoon I Use, Care, and Installation Guide
1. PC board located behind the light panel.
2. (If applicable) Remove both spacer panels by
2 screws for each spacer panel.
3. Remove 5 screws attaching light panel.
7 8 7
5 6
3 4
1 2
5
3
1
J u m p e r 3 - 4
Max. Blower CFM
AK9228BS & AK9234BS - 390
PC Board
AK9240BS & AK9246BS - 590
ACT™ Conversion
FIG. J
Jumper Pins
Plastic
7 8 Jumper
5 6
3 4
1 2
J u m p e r 5 - 6 or 7-8
DEFAULT POSITION
Default Max. Blower CFM
8 7
6 5
4 3
2 1
J u m p e r 1 - 2
Max. Blower CFM
AK9228AS & AK9234BS - 290
AK9240AS & AK9246BS - 390
FIG. K
8
6
4
2
