mm
(inch)
A
B
mm (inch)
Width between wheels (A)
Height floor-basic plate (E)
(top/mid/bottom position)
Back width, inside (B)
Overall width 22" (C)
Distance between 22" wheels w/
drum brakes (A)
Distance between 22" wheels wo/
drum brakes (A)
Length, with 22" wheels (G)
Overall height push brace 15° (F)
Overall height push brace 30° (F)
Hand brace length (D)
Seat plane angle
Folded height, without back wheels
(mid position)
Folded length, with 22"
Handrim diameter
Footrest to adaptorplate
Max load
Max load at transportation
Total mass
(22" air wheels+air front wheels)
E
1
340 mm (13½")
395 / 425/ 455 mm
(15½ / 16¾ / 18")
245 mm (9¾")
590 mm (23¼")
430 mm (17")
440 m (17¼")
750 mm (29½")
915 mm (36")
850 mm (33½")
225 mm (8¾")
0-30° / 35° / 40°
400 mm (15¾")
850 mm (33½")
480 mm (19")
50 - 340 mm (2-13½")
50 - 340 mm (2-13½")
100 kg (220.4 lb)
100 kg (220.4 lb)
14 kg (30,8 lb)
G
2
390 mm (15¼")
395 / 425/ 455 mm
(15½ / 16¾ / 18")
295 mm (11½")
640 mm (25¼")
480 mm (19")
490 mm (19¼")
750 mm (29½")
915 mm (36")
850 mm (33½")
225 mm (8¾")
0-30° / 35° / 40°
400 mm (15¾")
850 mm (33½")
480 mm (19")
100 kg (220.4 lb)
100 kg (220.4 lb)
14 kg (30,8 lb)
34
D
F
3
440 mm (17¼")
395 / 425/ 455 mm
(15½ / 16¾ / 18")
345 mm (13½")
690 mm (27¼")
530 mm (20¾")
540 mm (21¼")
800 mm (31½")
915 mm (36")
850 mm (33½")
225 mm (8¾")
0-30° / 35° / 40°
400 mm (15¾")
850 mm (33½")
480 mm (19")
50 - 340 mm (2-13½")
100 kg (220.4 lb)
100 kg (220.4 lb)
14 kg (30,8 lb)
support.R82.org
