INSTALLATION MANUAL
WARNINGS
Safety is guaranteed if these instructions are followed and therefore they
must be kept. Installation may require qualified personnel to be involved.
Before proceeding with installation of the device ensure that the
environmental conditions are in compliance with and suitable for the
product characteristics. Before any operation on the device remove mains
power.
CONFIGURATIONS
The instructions for installation and use in this manual apply to all
configurations of the POLAR units among which there are differences.
POLAR, POLAR R1 and POLAR XS refer to the configurations of units with a
single LED cluster. The model POLAR SWS refers to the configuration with
individual LED cluster and switch (C) to be used only in conjunction with
SLOTTY device provided by DomusLine. POLAR XL2 and POLAR XL3 refer to
the configurations of the devices that incorporate two or three LED
clusters. The POLAR TW (Tunable White) model is the configuration
incorporating a LED source with dynamic regulation of the light colour; for
POLAR TW units to work properly they must only be connected to the
DOMUS Line control unit (for example MAGIC BOX, MAGIC TUNE, TOUCH
TW, ...) which are supplied separately. For detailed information regarding
the characteristics and models of the systems regulating DOMUS Line's
Tunable White regulation system's characteristics and models please visit
www.domusline.com or contact us.
EN
POLAR - POLAR R1-POLAR SWS INSTALLATION
POLAR and POLAR R1 units are recommended for installation under
kitchen wall units and against the wall which makes it possible to hide the
cable behind the wall unit with regard to the fitting plan. As regards special
requirements, it is nonetheless possible to install these units in other
positions as long as they do not interfere with the integrity of the wire
and/or connector installed on it. Installation is possible with the unit's
power cable axially or radially with regards to the fitting plan.
CAUTION: POLAR SWS has a multi-pole connector 6-way and can only be
connected to the device provided by SLOTTY DOMUS Line.
- Fit the screws (B) supplied in the holes in the unit (A) as indicated in Fig. 1
and 2.
POLAR XS INSTALLATION
The POLAR XS unit is recommended for installation under wall units or
shelves. Installation can be done with the power cable to the light
positioned axially or radially with regard to the fitting plan.
- Fix the screws (B) supplied in the holes of the unit (A) as indicated in
Fig. 3.
POLAR XL2 – POLAR XL3 installation
The POLAR XL2 and POLAR XL3 units are recommended for installation
under wall units or shelves. Installation can be done with the power cable
to the light positioned axially or radially with regards to the fitting plan.
