Guide d'installation et mode d'emploi DEVIreg™ Multi
5
Schéma de raccordement
Schéma de raccordement DEVIreg™ Multi
Power
110/230 V AC
Channel #1
<I
CMR #1
S - temperature Sensor;
CMR - Current Monitoring Relay
Schéma général de raccordement du régulateur MCX08M2
PWM-PPM
0/10 V
0/10 Vdc
optoinsulated
34
Channel #2
Channel #3
<I
<I
CMR #2
CMR #3
To the AI
(120 mA max)
To the AI
(100 mA max)
NTC, 0/1 V, 0/5 V,
0/10 V, PT1000
Channel #4
Channel #5
<I
<I
CMR #4
CMR #5
CMR #6
Channel #6
Channel #7
Dev ice
<I
<I
OFF
CMR #7
FEC | Produced by Danfoss ©
RS485
(Modbus)
Alarm
RS485
ON
