Front Panel; Rear Panel - Samsung HT-E4530 Mode D'emploi

Getting Started

Front Panel

DISC TRAY
| NOTE |
\ To upgrade the product's software through the USB Host jack, you must use a USB memory stick.
\ When the product displays the Blu-ray Disc menu, you cannot start the movie by pressing the 6 button on the product or
the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the E button.

Rear Panel

COOLING FAN
LAN TERMINAL
SPEAKERS OUT
SURROUND
SURROUND
SPEAKER OUTPUT
CONNECTORS
| NOTE |
\ Ensure a minimum of 4 inches of clear space on all sides of the home theater to ensure adequate ventilation. Do not
obstruct the cooling fan or ventilation holes.
12
|
English
HT-E4530_ZC_ENG_0316.indd 12 HT-E4530_ZC_ENG_0316.indd 12
All manuals and user guides at all-guides.com
PLAY/PAUSE
FUNCTION
DISPLAY
REMOTE CONTROL
SENSOR
SPEAKERS OUT
LAN
SURROUND
SURROUND 5V 350mA
WIRELESS LAN
LAN
5V 350mA
HDMI OUT
WIRELESS LAN
WIRELESS LAN HDMI OUT
ENTER
STOP OPEN/CLOSE
VOLUME CONTROL
USB HOST
AUX VIDEO
IN OUT
FM ANT
OPTICAL
DIGITAL
HDMI OUT
AUDIO IN
AUX IN VIDEO OUT
AUX VIDEO
IN OUT
OPTICAL
DIGITAL
AUDIO IN
EXTERNAL DIGITAL
AUDIO IN (OPTICAL)
POWER
FM ANTENNA
FM ANT
