Contents Precautions Misure di precauzione About Your Product Informazioni sul prodotto Product Use Utilizzo del prodotto Product Maintenance Manutenzione del prodotto Troubleshooting Risoluzione dei problemi Product Specification Specifiche del prodotto Vorsichtsmaßnahmen Precauciones Übersicht Descripción general del Producto Montage Uso del Producto Wartung Mantenimiento del Producto Störungsbehebung...
• Toutes les données et toutes les notes techniques de ce manuel sont établies sur la base des résultats de tests du laboratoire de Ultenic et Ultenic se réserve le droit de l'interpréta- tion finale.
Station de chargement APP DOWNLOAD AND CONNECTION GUIDE Search for Ultenic APP on App Store (IOS devices) or Google Play (Android devices). Or you could scan the QR Code below to download the APP. Step �: Once the unit has been assembled, ensure that it is fully charged and press the power button to switch it on.
Schéma de l'indicateur de l'affichage Indicateur des forces d'aspiration Indicateur WiFi Indicateur de séchage à l'air de la brosse à rouleau. Indicateur de bactériostase Indicateur du de la brosse à rouleau. mode de stérilisation Indicateur du Indicateur du mode mode SMART d'absorption d'eau SMART MAX Indicateur...
Utilisation de votre produit Montage 1. Pour installer la poignée, insérez-la directement dans l'appareil jusqu'à ce que vous entendiez un clic. 2. Pour démonter la poignée, utilisez un outil (tel qu'un tournevis) pour dégager la poignée en appuyant sur le ressort, puis soulevez la poignée dégagée hors de cet appareil. Cliquer Chargement 1.
Fonctionnement 1. Appuyez sur le bouton d'alimentation pour 2. Appuyez sur le bouton de changement faire démarrer cet appareil par défaut en de fonction pour changer entre les mode SMART. Appuyez à nouveau sur ce modes SMART, MAX, stérilisation et bouton pour éteindre cet appareil.
7. Lorsque cet appareil est chargé sur la station de charge, vous pouvez appuyer sur le bouton d'autonettoyage pour nettoyer automatique- ment la laveuse de sols et le tube. Après l'autonettoyage, la lampe bactériostatique et le ventilateur s'allument automatiquement après un délai de 5s. 8.
Entretien de votre produit Pour obtenir les meilleures performances et éviter les odeurs, nettoyez et séchez soigneusement le réservoir d'eau propre, le réservoir des eaux usées, le filtre, la brosse de nettoyage, Couvercle latéral de brosse à rouleau, la brosse à rouleau et le couvercle de la brosse à...
Brosse à rouleau autonettoyante 1. Après utilisation, remettez cet appareil sur la station de charge pour l'autonettoyage. Appuyez sur le bouton d'autonettoyage pour lancer le processus. 2. Après l'achèvement du nettoyage, vous entendrez le message vocal "Nettoyage terminé, veuillez nettoyer le réservoir des eaux usées".
Couvercle de la brosse à rouleau 1. Prenez la poignée avant tout en maintenant le bouton enfoncé, et tirez vers le haut pour la retirer. 2. Rincez à l'eau. 3. Assurez-vous que le couvercle est bien bloqué en place lorsqu'il est installé, afin d'éviter les fuites d'eau.
Dépannage Problème de panne Cause possible Solution L'appareil n'est Protection automatique Redémarrez-le après le refroidissement pas démarré contre la surchauffe Appuyez sur la tête de la laveuse de sols, Ne fonctionne pas appuyez sur la poignée et passez en état après le démarrage La machine se dresse debout de fonctionnement.
Spécifications du produit Modèle du produit WashVac AC1 Tension de charge 100~240V 21.6V, 4000mAh Tension et quantité d'électricité 200W Puissance nominale Temps de fonctionnement SMART: ~45min MAX: ~25min Temps de charge 4 heures Débit d'eau 45~200mL/min 1 Litre 1 Litre Étanchéité...
Page 15
• Turn off this appliance before making any adjustments, replacing accessories, or storing this appliance. • WashVac AC1 can only be used, charged, and stored in a dry room where the temperature is higher than 4℃ but lower than 35℃.
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Charging Base Brush Solution APP DOWNLOAD AND CONNECTION GUIDE Search for Ultenic APP on App Store (IOS devices) or Google Play (Android devices). Or you could scan the QR Code below to download the APP. Step �: Once the unit has been assembled, ensure that it is fully charged and press the power button to switch it on.
Display Indicator Diagram WiFi Indicator Suction Power Loop Roller Brush Air Drying Indicator Bacteriostasis Sterilization Mode Indicator Indicator SMART Mode Suction Mode Indicator SMART MAX Indicator MAX Mode Fan Abnormal Indicator Indicator Roller Brush Error Error Indicator Indicator Accessories Cleaning Tool: Can be used to clean dirty water tank and tube.
Product Use Assembly 1. To assemble the handle, insert it directly into the appliance until you hear a click. 2. To disassemble the handle, use a tool (such as a screwdriver) to release the handle by pressing the spring, and then lift the released handle from the appliance. Click Charging 1.
Page 20
Operation 1. Press the power button and the appliance 2. Press the function button to switch will start in SMART by default. Press it among SMART, MAX, Sterilization and again to turn off. Suction Modes. 3. Long-press the power button for 5s to 4.
7. When the appliance is charged on the charging base, you can press the self-cleaning button to automatically clean the roller brush and tube. After the self-cleaning, the Sterilization UV Light and fan will be turned on automatically after a delay of 5s. 8.
Product Maintenance To get the best performance and prevent odors, thoroughly clean and dry the clean water tank, dirty water tank, filters, cleaning tool, roller brush and roller brush cover, Roller brush side cover after each use. After maintenance, place the appliance vertically on the charging base and store them in a dry place indoors.
Page 23
Roller brush self-cleaning 1. After use, put this appliance back to the charging dock for self-cleaning. Press the self-cleaning button to start the process. 2. After completion, you will hear the voice prompt “Cleaning completed, please clean the dirty water tank”. Note: Before self-cleaning, the battery level should exceed 20%, the dirty water tank should be emptied, and the water level of the clean...
Page 24
Roller brush top cover 1. Grab the front handle while holding down the button, and pull up to remove it. 2. Wash it with water. 3. Make sure the cover is locked in place when installed, to avoid water leakage. click Roller Brush 1.
Page 25
Install the filter; Clean the filter and tube The filter is dirty or the tube the motor is blocked. Error indicator flashes Shut down and restart after 2 minutes. If it still doesn't work, please contact the Voice prompt: Motor fault customer service: support@Ultenic.com Fan error...
Product Specification Product model WashVac AC1 Charging input 100~240V 21.6V, 4000mAh Voltage and electric quantity Rated power 200W Running time SMART: ~45min MAX: ~25min Charging time Water flow rate 45~200mL/min Clean Water Tank Capacity Dirty Water Tank Capacity Water Resistant...
