OPERATION

Turn on the MONITOR

Press and hold the POWER button on the front of the monitor.
Pairing the Camera(s) and Monitor
The camera and monitor come paired (connected) to each other automatically. However, if upon opening
this package the devices do not automatically connect and transmit, you may do so manually.
Note: Before you begin pairing, be sure to have the monitor and the camera(s) side by side.
1.
To pair your camera and monitor, press the MENU
on the front of the monitor, highlight the PAIRING icon and press the MENU
to select.
2.
Use the navigational arrows – + to select the
3.
Press MENU . When you see
PAIRING button on the side of the camera. A checkmark
confirming pairing is successful. Video/audio will be transmitted automatically.
4.
To pair additional cameras, repeat steps 1 to 3 and be sure to select camera number
or in the Pairing menu when pairing each additional camera.
ICONS ARE ORANGE
WHEN SELECTED
button. Using the navigational arrows
button once
icon.
flashing next to camera icon, quickly press and hold the
will appear next to camera
PAIRING
BUTTON
12

Placement of the Monitor

This monitor can be placed on a tabletop.
• You can place the monitor on a tabletop by using the retractable table stand on the
back of the monitor. When not in use, simply tuck the table stand away into the back
of the monitor until you hear a "click".

Placement of the Camera

This camera can be placed on a tabletop or hung on the wall above the
area being monitored.
– +
• Place the camera within 15 feet of the area being monitored for best picture results.
• Do not place objects within 2 feet of the field of vision of the camera as the night vision will not
activate correctly if objects are too close.

Mounting the Camera on a Tabletop Safely

To increase the downward viewing angle of the camera, please insert the included camera wedge to t
bottom of the camera (see below).
1. Place the camera on a tabletop no less than 3 feet away from area being monitored.
2. Feed the power cord down the back of the table or use wall clips (not included) to secure the co
,
away so children cannot reach it.
3. Plug in the power cord, check the monitor to ensure that you are getting a clear view of the
area you are monitoring and there are no obstructions.
WITH
WEDGE
CAMERA
BOTTOM
13
