COnneCting an aUDiO DeViCe USing aUX in

This section explains how to connect the unit to an audio device.
This unit is equipped with one audio analog jack for connecting an audio device.
LAN
DC 14V 4A AUX IN
USB 5V 500mA
LAN
DC 14V 4A AUX IN
USB 5V 500mA
LAN
DC 14V 4A AUX IN
USB 5V 500mA
AUX IN
LAN
DC 14V 4A AUX IN
USB 5V 500mA
AUx IN
1. Connect AUX IN (Audio) on the back of the unit to the earphone jack of the external device or audio device.
2. Press the button on the top panel of the Wireless Audio with Dock repeatedly until the
display.
• Each time you press the button, the selection changes as follows :
; ; ; ;
• The selected mode is displayed in white in the Function Display.
`
Before moving or installing this product, be sure to turn off the power and disconnect the power cord.
