ASSEMBLY

Locate the system outside the manifold cabinet to control. Use a device box (65x65 / Ø65 mm) for the assembly.
ES
Insert the control module of radiant elements (AZRA6OUTPUT8Z) inside the manifold cabinet. Location and installation of
the module must comply the current electronic rules.
EN
Install the thermostats as needed to perform the control of the system. Please remember, it is necessary to insert the battery
for wireless thermostats.
FR
IT
PT
DE

CONNECTION

Important: Respect the color code for all the system elements.
24
Nº Description
Airzone connection bus
SW1
Automation bus
