POWER ON Light
Each control knob will activate the POWER ON light. The light will
glow red when any control knob is on.
Coil Elements and Burner Bowls
(on some models)
Coil elements should be level for optimal cooking results. Burner
bowls, when clean, reflect heat back to the cookware. They also
help catch spills.
Cookware should not extend more than 1/2" (1.3 cm) over the
coil element. If cookware is uneven or too large, it can produce
excess heat causing the burner bowl to change color. For more
information, see the "General Cleaning" section.
Starting in June 2018 Whirlpool is equipping this product
with new temperature-limiting coils pursuant to the updated
standards in UL858. These new coils may vary cooking times
compared to your old cooktop, e.g., a slightly longer time to
boil large volumes of water.
NOTE: Before removing or replacing coil elements and burner
bowls, make sure they are cool and the control knobs are in the
Off position.
To Remove:
1. Push in the edge of coil element toward the receptacle. Then
lift it just enough to clear the burner bowl.
2. Pull the coil element straight away from the receptacle.
3. Lift out the burner bowl.
To Replace:
1. Line up openings in the burner bowl with the coil element
receptacle.
2. Holding the coil element as level as possible, slowly push coil
element terminal into the receptacle.
3. When the terminal is pushed into the receptacle as far as it
will go, push down the edge of the coil element opposite the
receptacle.

Home Canning

When canning for long periods, alternate the use of surface
cooking areas, elements or surface burners between batches.
This allows time for the most recently used areas to cool.
Center the canner on the grate or largest surface cooking area
or element. On electric cooktops, canners should not extend
more than 1/2" (1.3 cm) beyond the surface cooking area or
element.
Do not place canner on 2 surface cooking areas, elements or
surface burners at the same time.
On ceramic glass models, use only flat-bottomed canners.
On coil element models, the installation of a Canning Unit Kit
is recommended. If a kit is not installed, the life of the coil
element will be shortened. See "Assistance or Service" for
ordering instructions.
For more information, contact your local agricultural
department. Companies that manufacture home canning
products can also offer assistance.

Cookware

IMPORTANT: Do not leave empty cookware on a hot surface
cooking area, element or surface burner.
Ideal cookware should have a flat bottom, straight sides and a
well-fitting lid, and the material should be of medium-to-heavy
thickness.
Rough finishes may scratch the cooktop. Aluminum and copper
may be used as a core or base in cookware. However, when used
as a base they can leave permanent marks on the cooktop or
grates.
Cookware material is a factor in how quickly and evenly heat
is transferred, which affects cooking results. A nonstick finish
has the same characteristics as its base material. For example,
aluminum cookware with a nonstick finish will take on the
properties of aluminum.
Cookware with nonstick surfaces should not be used under the
broiler.
Use the following chart as a guide for cookware material
characteristics.
COOKWARE
CHARACTERISTICS
Aluminum
Heats quickly and evenly.
Suitable for all types of cooking.
Medium or heavy thickness is best
for most cooking tasks.
Cast iron
Heats slowly and evenly.
Good for browning and frying.
Maintains heat for slow cooking.
Ceramic or
Follow manufacturer's instructions.
Ceramic glass
Heats slowly, but unevenly.
Ideal results on low to medium heat
settings.
Copper
Heats very quickly and evenly.
Earthenware
Follow manufacturer's instructions.
Use on low heat settings.
Porcelain
See stainless steel or cast iron.
enamel-on-
steel or cast iron
Stainless steel
Heats quickly, but unevenly.
A core or base of aluminum or
copper on stainless steel provides
even heating.
5
