Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.com/REACH

Accessories and spare parts

Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.

Scope of delivery

The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.

Symbols on the device

General warning symbol
Risk of a larger recoil moment

Description of the device

Illustration A
Telescopic pipe unlocking button
1
Joint
2
Adjustment lever joint
3
Upper telescopic pipe
4
Mount for spray lance
5
High-pressure nozzle, brown
6
Clip for nozzle mounting
7
High-pressure nozzle, white
8
Spray lance
9
Telescopic spray lance hose for connection to the
10
trigger gun
Lower telescopic pipe
11
Hook and loop strips
12
*Trigger gun
13
Holder for trigger gun
14
* Not included in the scope of delivery

Assembly

The spray lance, the existing trigger gun, the hose of the
telescopic spray lance and the high-pressure cleaner
hose must be installed before operating the device.
Install the high-pressure nozzle on the spray
Select the nozzle according to the high-pressure clean-
er used.
K 2, K 3, K 4, K 5: Use a brown high-pressure nozzle
K 6, K 7: Use a white high-pressure nozzle (already in-
stalled).
lance
Illustration B
1. Loosen and remove the slip for the nozzle mounting
from below with a small screwdriver.
2. Pull out the unused high-pressure nozzle.
3. Select the required high-pressure nozzle according
to the high-pressure cleaner used and press it in.
4. Insert the clip and secure the high-pressure nozzle.
Installing the spray lance
Illustration C
1. Insert the spray lance firmly into the adapter and fix
it with a 90° turn.
Mounting the trigger gun
1. Insert the trigger gun with the connected high-pres-
sure cleaner hose into the holder of the telescopic
spray lance.
Illustration D
2. Tighten one hook and loop strip over the top of the
trigger gun.
3. Tighten the other hook and loop strip over the back
of the trigger gun.
Connect the hose of the telescopic spray
lance to the trigger gun
Illustration E
1. Push the adapter of the hose into the mount of the
trigger gun.
2. Turn the hose until it latches into place.
Connecting high-pressure cleaner
Note
The high-pressure cleaner hose should be connected to
the trigger gun in accordance with the operating instruc-
tions of the high-pressure cleaner before it is installed in
the holder of the telescopic spray lance.
The telescopic spray lance comprises 2 individually ex-
tendable pipes that are connected with a joint. With the
help of the joint, the telescopic spray lance can be fixed
at different angles up to a maximum of 180°.
When extending the telescopic pipes and adjusting the
angle, the telescopic spray lance can be placed on the
gun holder.
1. Adjust the telescopic spray lance to the desired
length.
Illustration F
a Press and hold the telescopic pipe unlocking but-
ton.
b Extend the lower telescopic pipe to the desired
length.
c Release the telescopic pipe unlocking button.
The telescopic pipe is locked.
d If necessary, repeat the steps for the upper tele-
scopic pipe.
2. Adjust the angle of the telescopic spray lance.
Illustration G
a Push the adjustment lever towards the telescopic
pipe and keep it pressed.
b Hold one pipe and set the desired angle by mov-
ing the other pipe.
c Release the telescopic pipe adjustment lever.
3. Put the high-pressure cleaner into operation, refer to
operating instructions for the high-pressure cleaner.
English

Initial startup

Operation
