REVERSING THE DOOR SWING
4
TRANSFER BOTTOM HINGE TO
THE LEFT
Remove the bottom hinge, screws and shim(s) from
the right side and reassemble them on the left side of
the cabinet.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of one full turn
using both hands.
10
Installation Instructions
(CONT.)
TRANSFER CENTER HINGE TO
5
THE LEFT
Remove the two screws on the opposite side.
Remove the center hinge, shim and screw(s).
Reassemble the center hinge on the left side.
CAUTION: When assembled correctly, the hinge
is tight against the cabinet.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of 1/2 turn using
both hands.
