4. Installation of the main components

• The front and back sketch map of the main unit
Increasing power
switch
Decreasing power
switch
Options switch
Water control knob
Water entrance
Socket for power supply
• Sketch map for connection of foot switch, adapter and main unit
Plug of foot switch
Socket for
foot switch
Power cord plug
Socket for
power supply
GACD_240614_NoticeTriScallerCompact_V6.indd 3
Scaling indicator
3
en
Power indicator
Endo indicator
Perio indicator
fig 1
Power switch
Socket for foot switch
Foot switch
Power switch
Input voltage
220-240 V~
Power switch
fig 2
