• Use only the fixing screws supplied with the
product for installation or, if not supplied,
purchase the correct screws type.
• Use the correct length for the screws which
are identified in the Installation Guide.
• In case of doubt, consult an authorized
service assistance center or similar qualified
person.
WARNING! Do not use with a
programmer, timer, separate remote
control system or any other device that
switches on automatically.

Electrical connection

The mains power supply must correspond to the rating indicated on the
plate situated inside the hood. If provided with a plug connect the hood
to a socket in compliance with current regulations and positioned in an
accessible area, after installation. If it not fitted with a plug (direct mains
connection) or if the plug is not located in an accessible area, after
installation, apply a double pole switch in accordance with standards
which assures the complete disconnection of the mains under
conditions relating to over-current category III, in accordance with
installation instructions.
WARNING! Before re-connecting the hood circuit to the mains
supply and checking the efficient function, always check that the mains
cable is correctly assembled.
WARNING! If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified persons in order
to avoid hazard.
Installation
• The minimum distance between the supporting surface for the cooking
equipment on the hob and the lowest part of the range hood must be
not less than 50cm from electric cookers and 70cm from gas or mixed
cookers.
If the instructions for installation for the gas hob specify a greater
distance, this must be adhered to.
• This appliance is marked according to the European directive
2012/19/EC - UK SI 2013 No.3113 on Waste Electrical and Electronic
Equipment (WEEE).
• By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste
handling of this product.
• The symbol on the product, or on the documents
accompanying the product, indicates that this appliance may not be
treated as household waste. Instead it should be taken to the
appropriate collection point for the recycling of electrical and electronic
equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
• For further detailed information regarding the process, collection and
recycling of this product, please contact the appropriate department of
your local authorities or the local department for household waste or the
shop where you purchased this product.
Appliance designed, tested and manufactured according to:
• Safety: EN/IEC 60335-1; EN/IEC 60335-2-31, EN/IEC 62233.
• Performance: EN/IEC 61591; ISO 5167-1; ISO 5167-3; ISO 5168;
EN/IEC 60704-1; EN/IEC 60704-2-13; EN/IEC 60704-3; ISO 3741; EN
50564; IEC 62301.
• EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR 14-2; EN/IEC
61000-3-2; EN/IEC 61000-3-3. Suggestions for a correct use in order to
reduce the environmental impact: Switch ON the hood at minimum
speed when you start cooking and kept it running for few minutes after
cooking is finished. Increase the speed only in case of large amount of
smoke and vapor and use boost speed(s) only in extreme situations.
Replace the charcoal filter(s) when necessary to maintain a good odor
reduction efficiency. Clean the grease filter(s) when necessary to
maintain a good grease filter efficiency. Use the maximum diameter of
the ducting system indicated in this manual to optimize efficiency and
minimize noise.
Use
The hood is designed to be used either for exhausting or filter version.
Extraction version
In this case the fumes are conveyed outside of the building by means of
a special pipe connected with the connection ring located on top of the
hood.
CAUTION!
The exhausting pipe is not supplied and must be purchased apart.
Diameter of the exhausting pipe must be equal to that of the connection
ring.
CAUTION!
If the hood is supplied with active charcoal filter, then it must be
removed.
Connect the hood and discharge holes on the walls with a diameter
equivalent to the air outlet (connection flange).
Using the tubes and discharge holes on walls with smaller dimensions
will cause a diminution of the suction performance and a drastic
increase in noise.
Any responsibility in the matter is therefore declined.
! Use a duct of the minimum indispensable length.
! Use a duct with as few elbows as possible (maximum elbow
angle: 90°).
! Avoid drastic changes in the duct cross-section.
Filtration version
The aspirated air will be degreased and deodorised before being fed
back into the room.
