INTRODUCTION:
Congratulations! In purchasing the LAX 502/602/1002/1002D/1202 and 1202D you have acquired a mixing
console whose small size belies its versatility and audio performance.
With the microphone preamps including phantom power as an option. Balanced line input and a powerful effects
section. The mixing consoles in the LAX Series are optimally equipped for live and studio applications. Owing to
state-of-the-art circuitry your LAX console produces a warm analog sound that is unrivalled. The microphone
channels feature high-end LAX Mic Preamps that compare well with costly outboard preamps in terms of sound
quality and dynamics and boast the following features.
-130 dB dynamic range for an incredible amount of headroom
-A bandwidth ranging from below 10 Hz to over 20 KHz for crystal-clear reproduction of over the finest nuances
-The extremely low-noise and distortion-free circuitry guarantees natural and transparent signal reproduction
-They are perfectly matched to every conceivable microphone with up to 60 dB gain and +48 volt phantom
power supply
-They enable you to use the greatly extended dynamic range of your 24-bit / 192 kHz HD recorder to the full.
Thereby maintaining optimal audio quality
The equalizers used for the LAX Series are based on the legendary circuitry of top-notch consoles made in
Britain, which are renowned throughout the world for their incredibly warm and musical sound character. Even
with extreme gain settings these equalizers ensure outstanding audio quality.
MULTI EFFECTS PROCESSOR ( LAX 1002D & LAX 1202D )
Additionally, your LAX mixing console has an effect processor with 24-bit A/D converters included, which give
your 100 presets producing first-class reverb, delay and modulation effects plus numerous multi-effects in
excellent audio quality
