The scroll saw features a cast iron frame construction and
a solid aluminum table surface to ensure durability. This
tool may be used for the following purposes:
• Cutting wood, wood composition products, plastic, and
other fibrous material up to 2 in. thick
• Cutting nonferrous metals such as aluminum, brass,
and copper.
WARNING
Operating of any power tool can result in foreign objects
being thrown into the eyes, which can result in severe
eye damage. Always wear safety goggles complying with
United States ANSI Z87.1 before commencing power tool
operation.
WARNING
Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is suffi-
cient to inflict severe injury.
WARNING
Do not use any attachments or accessories not recom-
mended by the manufacturer of this tool. The use of at-
tachments or accessories not recommended can result in
serious personal injury.
WARNING
To prevent serious personal injury, never leave the saw
unattended until the blade has come to a complete stop.
CAUTION: Always observe the following safety precau-
tions.
SAFETY PRECAUTIONS
• When adjusting or replacing any parts on the tool, turn
switch OFF and unplug the power cord.
• Make sure saw is level and does not rock. Saw should
always be on a firm, level surface with plenty of room
for handling and properly supporting the workpiece.
• Secure saw to the supporting surface to prevent
slipping, walking or sliding during operations like cutting
long, heavy boards.
• Do not remove jammed cutoff pieces until blade has
come to a full and complete stop.
• Choose the right size and style blade for the material
and type of cut you plan to do.
• Use only recommended accessories.
• With the exception of the workpiece and related support
devices, clear everything off the saw table before turning
the saw on.
• Properly support round materials such as dowel rods or
tubing because they have a tendency to roll during a
cut causing the blade to "bite." To avoid this, always
use a "V" block or clamp workpiece to a mitre gauge
• Before removing loose pieces from the saw table, turn
saw off and wait for all moving parts to stop.
OPERATING INSTRUCTIONS
TURNING THE SCROLL SAW ON AND OFF
Refer to Figure 7
• Plug the unit into the appropriate power source.
• Push the ON/OFF switch to the ON position. Unit
should now be operating.
• To switch unit Off push the ON/OFF switch to the off
position. Unit should now be off.
• Disconnect cord from power source when saw is not in
use.
Figure 7
ON/OFF SWITCH
Refer to Figure 8
The ON/OFF switch is located on the front of the scroll
saw. To turn the machine ON, pull the switch to the up
position. To turn it OFF, push the switch to the down
position.
NOTE: When the machine is not in use, the machine
should be locked in the "OFF" position to prevent unau-
thorized use.
• To lock the machine, turn the switch to "OFF" position.
Pull the key out. The switch cannot be turned on without
the key.
• If the key is removed when the switch is at the "ON"
position, the switch can be turned off but cannot be
turned on again.
• To unlock, place the key into the slot on switch unit it
clicks into place.
Figure 8 On-Off Switch
22
ON/Off Switch
Variable Speed
Control Knob
