8. My Pen won't heat up!

(light stays red).

It takes around 60-90 seconds for your Pen to heat up. If, after

that time, the Pen still does not heat up and the Light remains

RED, turn the Pen ON and OFF and try again. If that still does not

work, please contact us at help@the3Doodler.com and we will

assist further.

SECTION 4: TIPS AND BEST

PRACTICES

Pay attention to Plastic types

and settings

• For optimal Doodling, we suggest using the correct temperature

settings for your Plastic.

• DO double check which type of Plastic you are using before you

turn on the 3Doodler Create+ and insert a Plastic strand. If your

Plastic strands get mixed up, here is a handy table for sorting and

identifying what you're working with.

ABS (MATTE):

Temp: ABS / FLX Temp

Light: BLUE

Feature: Great for drawing in the air.

How to tell: Plastic has white

semi-circle ends.

PLA (GLOSSY / CLEAR /

METALLIC / SPARKLE ):

Temp: PLA Temp

Light: GREEN

Feature: Gossy and making it perfect

for artistic creations.

How to tell: Very rigid, no white

semi-circle ends.

FLEXY:

Temp: ABS / FLX Temp

Light: BLUE

Feature: Make flexible,

bendable Doodles.

How to tell: Plastic is very flexible.

Do not forget to snip your

Plastic ends

• After removing a Plastic strand

from the 3Doodler Create+, cut

and remove any partially melted

material at the end of your

strand before re-feeding it into

the 3Doodler Create+. This will

reduce blockages or clogging

issues.

Reverse and remove Plastic

correctly

• DO NOT pull Plastic from the back of the 3Doodler Create+

other than as directed.

BLUE Light

With the Pen set to ABS / FLX,

wait for the BLUE Light to

come on.

Snipped Ends

Unsnipped Ends

Flashing

BLUE

Double click either Speed

Button and the Light will start

flashing to signal the Plastic is

reversing.

Once the Plastic stops reversing, it is safe to remove it from the

Pen by gently pulling on the back of the strand.

Take a break

• DO give your 3Doodler Create+ a rest after every 2 hours of

continuous Doodling. 30 minutes of down time should be plenty.

Treat your Nozzle right

• If you ever remove your

Nozzle, DO NOT remove it

when your 3Doodler Create+

is cold. Light should be BLUE

or GREEN.

• If you ever need to tighten

your Nozzle, DO NOT force

the Nozzle or overtighten it,

as you could break the Nozzle

and permanently damage your

3Doodler Create+.

Specifications are subject to change and improvement without notice.

SPECIFICATIONS

SPECIFICATION OF POWER ADAPTER

Output Power: 6W

Input: 100-240V AC, 0.5A MAX, 50-60Hz

Output Voltage: 5V

Output: +5V DC, 1.2A

Input Voltage: 5V

CARE & MAINTENANCE

For care and maintenance information, and more advice on how to use your

3Doodler Create+, please refer to our website: the3Doodler.com

3Doodler, please refer to our website: the3Doodler.com

To troubleshoot, please visit: the3Doodler.com/troubleshooting

LIMITED WARRANTY

For more details on your limited warranty, please visit:

the3Doodler.com/warranty

For more details on your limited warranty, pleae visit:

the3Doodler.com/warranty

For 3Doodler's Terms and Conditions and other notices please refer to our

For 3DoodlerÕs Terms and Conditions and other notices please refer to our

website: the3Doodler.com/terms-and-conditions

This marking indicates that this product should not be disposed

of with other household wastes. To prevent possible harm to the

environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material

resources.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by

the party responsible for compliance could void the user's authority to

operate the equipment.

NOTE: This equipment has been tested and found to comply with the lim-

its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

This marking indicates that this product should not be disposed of with

harmful interference to radio or television reception, which can be

other household wastes. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, recycle it responsibly to

determined by turning the equipment off and on, the user is encouraged

promote the sustainable reuse of material resources.

to try to correct the interference by one or more of the following

measures:

This device complies with part 15 of the FCC Rules. Operation is subject to the

- Reorient or relocate the receiving antenna.

following two conditions: (1) This device may not cause harmful interference, and

- Increase the separation between the equipment and receiver.

(2) this device must accept any interference received, including interference that

- Connect the equipment into an outlet on a circuit different from that to

may cause undesired operation.

which the receiver is connected.

- Consult the dealer or an experienced radio/ TV technician for help.

CAN ICES-3 (B)/NMB-3(B)

BLUE or

GREEN Light
