3Doodler create+ Mode D'emploi page 3

Step 1: Turn on your 3Doodler
Create+ and wait for it to heat up
1
Power Adapter
Plug in the yellow hole of
3Doodler Create+.
3
Light will glow RED while the Pen is reaching the temperature
required to melt your Plastic. Once Light has turned BLUE,
your Pen is ready to extrude Plastic.
Step 2: Load and extrude Plastic
1
Select one strand of ABS
(MATTE) Plastic (provided in
your 3Doodler Create+ box).
3
x1
Click FAST button once and
release. You will hear the
Drive Gear start.
5
x1
Press the FAST button once to
stop extruding.
2
Slide Control Switch to
ABS / FLX.
60-90
secs
Light to BLUE
2
BLUE Light
Making sure the Light is still
BLUE, push the Plastic through
the Plastic Loading Port.
4
After 10-15 seconds, Plastic
will begin extruding from the
Nozzle. Extruded Plastic will
harden after a few seconds.
3
Step 3: Doodle your name
Use box below to create your first Doodle -
your name!
1
Write your name in the box
provided using marker, pen,
pencil, or any other writing
utensil of your choice. We
suggest cursive, or block with
the letters connected.
3
Doodle your name in a
continuous unbroken Doodle
by dragging the Plastic along
the paper as if you were
writing with a pencil, with all
letters connected. Keep your
movement slow and steady.
5
Bend the paper outwards to
pop your Doodled name off.
Your Name:
#MyFirstDoodle
2
Click FAST button once. When
Plastic starts extruding, push
Nozzle down into paper to get
Plastic to stick to surface.
4
x1
When you reach the end of your
name, stop extruding by clicking
the FAST button once again.
4
