Step 7: Let's Switch to PLA Plastic!
BLUE
1
light
PLA
Plastic
With Pen on ABS / FLX, load a
new strand of PLA Plastic into
Plastic Loading Port. Use a
different color to the ABS you
were using before.
Light to RED
3
Light to GREEN
Switch Pen to PLA setting. Wait
for Light to turn GREEN.
Step 8: Power Down
1
x2
Remove all Plastic from the
Pen using the Reverse feature
(double click any Speed
Button). Friendly reminder to
snip those ends!
3
Power Adapter
Allow your 3Doodler Create+
to cool completely
before storing.
NOTE:
After 5 minutes of inactivity, the 3Doodler Create+'s heating
system will automatically power down. You will need to press one
of the Speed Buttons OR toggle the Control Switch OFF and then
ON again to continue use.
TAKE A BREAK:
We recommend powering down and giving your 3Doodler
Create+ a 30 minutes break after every 2 hours of
continuous use.
2
x1
PLA Plastic
ABS Plastic
The color of the Plastic will
change once the PLA starts
extruding. It will appear mixed
at first. STOP extrusion by
pushing either button once.
4
x1
Click FAST or SLOW once to
continue extruding the PLA
Plastic and Doodle as you wish.
2
Move the Control Switch
to OFF.
7
SECTION 3: TROUBLESHOOTING
Tools (Provided in Box)
Before showing you how to troubleshoot issues
with your 3Doodler Create+, we want to introduce
you to three handy tools provided in your box:
SLOW
FAST
Mini Spanner
Used for tightening and
removing the Nozzle.
Do not remove Nozzle
when Pen is cold.
Do not overtighten the
Nozzle, as you may
break it.
With those introductions over, it's time to look
at the different issues that may arise with your
3Doodler Create+ and steps to get back
to Doodling.
Unblocking Tool
Used for pushing short
pieces of Plastic down
into the Drive Gear to
help with extrusion
from Pen.
