Spécifications
525-600 V
Puissa
nce Bussmann Bussmann
[kW Type RK1 Type J
(HP)]
0,75-1, KTS-R-5 JKS-5
1
(1,0-1,5
)
1,5-2,2 KTS-R-10 JKS-10
(2,0-3,0
)
3,0 KTS-R15 JKS-15
(4,0)
4,0 KTS-R20 JKS-20
(5,0)
5,5 KTS-R-25 JKS-25
(7,5)
7,5 KTS-R-30 JKS-30
(10,0)
11 KTS-R-35 JKS-35
(15,0)
15,0 KTS-R-45 JKS-45
(20,0)
18,5 KTS-R-50 JKS-50
(25,0)
22,0 KTS-R-60 JKS-60
(30,0)
30,0 KTS-R-80 JKS-80
(40,0)
37,0 KTS-R-100 JKS-100
(50,0)
45,0 KTS-R-125 JKS-125
(60,0)
55,0 KTS-R-150 JKS-150
(75,0)
75,0 KTS-R-175 JKS-175
(100,0)
Tableau 8.21 525-600 V, tailles de boîtier A, B et C
MG33AT04
Manuel d'utilisation
Taille de fusible max. recommandée
Bussmann Bussmann Bussmann
Type T Type CC Type CC
JJS-6 FNQ-R-5 KTK-R-5
JJS-10 FNQ-R-10 KTK-R-10
JJS-15 FNQ-R-15 KTK-R-15
JJS-20 FNQ-R-20 KTK-R-20
JJS-25 FNQ-R-25 KTK-R-25
JJS-30 FNQ-R-30 KTK-R-30
JJS-35 – –
JJS-45 – –
JJS-50 – –
JJS-60 – –
JJS-80 – –
JJS-100 – –
JJS-125 – –
JJS-150 – –
JJS-175 – –
