sigfox REFERENCE TRANSMITTER - Guide utilisateur / User guide version V1.0.0
2.2.2
Transmission period configuration
The product allow to choose between 2 transmission periods with the switch n°3:
•
A-Period : to send data every 10 seconds
•
B-Period : to send data every 1 minute
Switch n°3 value
OFF
FR
EN
A-Period
2.3. Operation of the LEDs
Product state
OFF
ON (OPERATING MODE) Start-up of the product
ON (OPERATING MODE) Frame transmission
COMMAND MODE
ON (OPERATING MODE
- low battery)
ON (DEFAULT)
2.4. Frames transmission
The sigfox REFERENCE TRANSMITTER sends frames :
•
At start-up
•
Following a change on DIP switch (automatic detection of change)
•
Periodically according the transmission period configuration (switch n°3)
ON
B-Period
Description
Produit OFF
Switching to the Command
mode
Battery level low
Product faulty (return to
factory)
LED red state
LED green state
OFF
OFF
50ms ON / 30s OFF
50ms ON / 30s OFF (just before
the red LED)
OFF
Rapid flashing at beginning of
transmission
Fixed ON
Fixed ON
Flashing (1s ON
OFF
every 30s)
Fixed ON
OFF
Page
Page
14
14
of 30
of 30
