shoulder straps are aligned with your child' s shoulders. Adjust the height by sliding the buckles [16e] behind the headrest up or
down.
• Connect the two shoulder strap buckles together and insert them into the center buckle [16b] on the crotch strap [16d] until you
feel it snap. Reduce the length of the crotch strap and the shoulder belts so that your child is securely tightened. Verify that the
safety harness is locked by pulling both shoulder belts.
[17] Reclining the seat
• Slide the recline handles [17a] towards each other [17b] to unlock the backrest and roll the backrest to the back or front [17c].
• When the backrest reaches the next recline position, the recline handles slide outwards automatically and lock the backrest in
place.
• Always make sure the backrest is securely locked inplace when using the Outback.
[18] Mounting the LED lights
• Place the lights on the side of the trailer that is most exposed to the road.
• Rear: Attach the red LED light on the push bar at the back of the trailer.
CARE AND MAINTENANCE
Check before using the trailer
• The wheels are properly secured to the trailer.
• The tires are inflated according the specified tire pressure
• The trailer is unfolded properly and the mechanism is locked on both sides. Do not forget to lock the push bar.
• The seat back rest is well secured and tightened. Please see the maintenance section.
• The safety flag and lights are in place whenever required.
Storage
• It is highly recommended to store the Outback trailer indoors, in a dry and well-ventilated area out of direct sunlight.
TIP: There is a Hamax storage cover available for better protection.
Maintenance
• Push bar: In case the push bar slips from its position, tighten the nut [19] under the fabric of the push bar. Make sure the nuts
are tightened equally on both sides.
• Parking brake [2m]: Adjust the parking brake cable by setting the cable adjuster [20] near the brake pedal.
• Safe connection point [2e]: If dirt is inside the safe connection point [2e], rinse it with water.
• Seat base back rest [2j]: Regularly tighten the straps [21] at the rear of the seat base back rest. Make sure that you start to
tighten it at the top and follow by tightening it at the bottom.
• Do not use cleaning solvents. Clean only with mild soap and water.
• The seat paddings [2d] can be removed from the trailer for cleaning purposes. Wash seating by hand or using cold machine
wash with a short spin cycle.
• Allow the trailer to dry completely before storing it to prevent it from becoming moldy.
• If the trailer is involved in an accident or is damaged, contact your dealer to check if it can still be used.
• All important components such as: drawbar, connecting device, frame, safety belts, lighting equipment, tires, and wheels, etc.
for safe condition; regular verification whether bolted assemblies are well tightened.
WARRANTY
The Hamax Outback Multifunctional Child Carrier is warranted from the date of purchase. The warranty period depends on the
law of the country in question. The warranty applies to defects in materials or workmanship, and does not cover damage due
to improper use, lack of maintenance, failure to follow the user manual, use of force or normal wear and tear. The warranty is
valid for the original user only. Please read the use and maintenance recommendations carefully. Conditions that may cause
premature wear of the carrier may not be covered by the warranty. Should the carrier require service or you want to make a
warranty claim, please contact your local dealer from whom you purchased your carrier.
GENERAL INSTRUCTIONS FOR BATTERIES (REAR LIGHT)
• Non-rechargeable batteries must not be charged.
• Remove rechargeable batteries from the item before charging them.
• Different types of batteries as well as old and new batteries must not be used together on the same item.
• Only batteries of the same or equivalent type as specified should be used.
• Please make sure that the batteries are inserted with the correct polarity.
• The supply terminals must not be short-circuited.
• Remove empty batteries from the item.
p. 13
• It is not allowed to burn empty batteries as they might explode or leak.
Information concerning the disposal of exhausted batteries
The pictured symbol on the left side on batteries, the packing or the enclosed documents signifies that
the batteries should not be disposed of at the end of their life cycle together with the domestic waste.
Possible added letters under the waste bin signify that the battery contains lead (Pb), cadmium (Cd) or
mercury (Hg). You as consumer are obliged by law to render all kind of batteries (both rechargeable as
well as non-rechargeable) inclusive button cells at local places of collection or at the retail market. This
is at no charge. The proper disposal enables the recycling of valuable resources and avoids possible
negative effects on humans and the environment.
Information concerning the disposal of old electric and electronic products
The pictured symbol on the product, the packing or the enclosed documents signifies that the product
should not be disposed of after the end of its life cycle together with the domestic waste. You as
consumer are obliged by law to render electric and electronic products at a local place of collection for
electronic equipment. This is at no charge. Please take out the batteries before disposal of the product.
The proper disposal enables the recycling of valuable resources and avoids possible negative effects
on humans and the environment. For further information please contact your local authority or the
vendor of the product.
