1. DESCRIPTION.

Electronic thermostat for temperature control in the services sec-
tor (heating and air conditioning) . Input terminals for temperature
reduction and central switching between heating/air-conditioning .
6(2) A 230 V~ change-over relay output, supply voltage 120-230 V~
50-60 Hz - 2 modules .

2. FIELD OF APPLICATION.

The appliance is designed to control room temperature by acting on
the control circuit of the burner or circulation pump (heating) or on
the control circuit of the air conditioner (air conditioning) .
The large display shows the room temperature, system operating
status and mode (heating, air conditioning, reduction) .
Parameters are programmed with the 4 buttons on the front of the
appliance .
With the 2 remote controls it is possible to centralize the summer/
winter function and temperature reduction .
16 - ENGLISH

3. INSTALLATION.

The appliance must be installed in flush or surface mounting boxes
with EIKON frames and plates at a height of 1 .5 m off the floor in
a suitable position for correctly detecting the ambient temperature .
It must not be installed in niches, behind doors and curtains or in
areas affected by sources of heat or atmospheric factors . In par-
ticular, it must not be installed on outer walls or in association
with appliances that generate heat (e.g., dimmers or lamps).
It should be used in dry, dust-free places at a temperature between
0 °C and +40 °C .
