5 - TECHNICAL FEATURES
ASSEMBLY OF THE PELLET TRANSPORT PIPE
•
Free the earthing wire by about 5 cm at each end of the T2 pipe and fold into the pipe.
EARTHING WIRE
•
Slide the locking devices on the pipe and insert them into the connections. The earthing wire must must have good contact with the
connections, otherwise file the coating off the pipe.
If one has difficulty in inserting these devices, moisten them with water (do not use grease).
Be careful not to invert the flow and return pipes.
The table below shows the minimum bending radius of pipes T1 and T2.
52
Fully tighten the locking clamps.
T2
r min.250 mm
T1 = AIR PIPE
T2 = PELLETS PIPE
T1
min.30 cm
EN
