Instructions for installation and use

1.4. ALASKA MINI INFRA+ parts list

No. of items
Base frame
1 Base frame
1 Base frame
1 Base frame
1 Base frame
Wall elements
1 A/B wall element with radiator recess
1 A/B wall element with Multiclip
1 A/B ventilation element with Multiclip
4 A/A wall elements with Multiclip
1 A/A electrical element with Multiclip
1 Element above door, floor plan (right)
1 Element above door, floor plan (left)
Ceiling elements
2 Ceiling elements
Corner posts
3 90° corner posts with Multiclip
1 Corner post with front hinge for glass door with Multiclip
1 Post for glass element, 8 mm groove
Support slats
2 Roof support slats
2 Roof support slats
2 Roof cover slats
2 Roof cover slats
2 Bench support slats
2 Mounting slats for bench screen
Name
p. 6/32
Dimensions
156 x 9 x 4 cm
108 x 9 x 4 cm
102 x 9 x 4 cm
64 x 9 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 58 x 4 cm
81.5 x 10.1 x 4 cm
81.5 x 10.1 x 4 cm
146 x 49 x 4 cm
193 x 6 x 6 cm
202 x 6 x 7.5 cm
202 x 4.5 x 4 cm
140 x 4 x 4 cm
100 x 4 x 4 cm
144 x 1.2 x 4 cm
104 x 1.2 x 4 cm
58 x 4 x 4 cm
26 x 4 x 4 cm
