Item Function
1 Bargraph
2 Display (values and units of measurement)
3 Nature of the measurement (AC or DC)
4 Automatic measurement range selection mode
5 Low battery indicator
6 Audible continuity test
Diode test
7 Display of the modes selected
8 Non-Permanent Mode : automatic switching off
of the device activated
1.1.1 The symbols on the display unit
The display unit uses the following symbols :
Symbol Designation
AC Alternating current
DC Direct current
AUTO
Automatic change of range (see § 1.1.3)
HOLD Storage and display of stored values
MAX Maximum RMS value
MIN
Minimum RMS value
REL Relative value
O.L Overshoot of measurement capabilities (see §1.1.2)
V Volt
Hz Hertz
% Duty Cycle
F Farad
° C
Degrees Celsius
° F Degrees Fahrenheit
A Ampere
English
See §
3.1
3.2.1
3.2.2
5.2
3.1.3
3.1.4
1.2
3.2.1
