LG LBNC122 1 Serie Manuel Du Propriétaire page 23

Assembling the Vegetable Drawer
Assemble the vegetable drawer in the reverse
order of the removal process.
Vegetable Drawer Cover
Removing the Cover
1
To remove the vegetable drawer cover, lift the
front with one hand and support underneath
the cover with the other hand. Tilt the cover 45
degrees and pull it forward to remove it.
2
After removing the vegetable drawer cover,
pull the front section of the crisper cover down.
3
Pull the crisper cover out to remove it.
Assembling the Cover
1
Slide the tabs at the back of the crisper cover
into the slots at the back of the drawer cover.
2
Push the front of the crisper cover up to snap
the front tabs into place.
3
Hold the vegetable drawer cover at a
45-degree angle and insert it into the
refrigerator. Supporting the cover with one
hand, bring the cover to a horizontal position
and lower it onto the guides. Push the cover
back into place.
Freezer Drawer
Removing the Freezer Drawer
1
Remove the contents of the drawer. Hold the
handle of the freezer drawer and pull it out
completely until it stops.
2
Lift the freezer drawer up and remove it by
pulling it out.
Assembling the Freezer Drawer
Assemble the freezer drawer in the reverse order
of the removal process.
MAINTENANCE 23
