Parts Diagram and List

13
14
NO. Part Number
1 360723001
2 399451045
3 360713015
4 336713574
5 360457020
6 921100054
7 336713573
8 360757012
360757014
9
10 360757015
922100013
11
12 360727004
360723002
13
14 360757007
360757006
15
English
15
12
1
Description
Parallel Box
Receptacle 14-50R
Parallel Box Panel
Outlet Cover 14-50R
LED Assy
Screw ST3.9X9.5
Outlet Cover L5-30R
Receptacle L5-30R
Circuit Breaker Amp 30A
Circuit Breaker Amp 50A
Nut M4
Cable Holder
Back Cover
Parallel Cable GEN 1
Parallel Cable GEN 2
11
10
9
2
3
Qty.
1
1
1
1
2
4
1
1
1
1
4
2
1
1
1
The Parallel Kit can be mounted using
4 X M6-1.0 screws(not included) before
connecting to the inverter.
04
8
4 5
6
Customer Service: 1-844-FIRMAN1
7
