Environmental protection

The packaging material can be recy-
cled. Please arrange for the environ-
mentally appropriate disposal of the
packaging.
Electrical and electronic devices often
contain components which could po-
tentially pose a danger to human
health and the environment if handled
or disposed of incorrectly. However,
these components are necessary for
the proper operation of the device. De-
vices marked with this symbol must not
be disposed of with regular household
rubbish.
Cleaning operations which produce
oily waste water, e.g. engine washes,
underbody washes, may only be car-
ried out using washing stations
equipped with an oil separator.
Work with detergents must only be per-
formed on liquid-tight work surfaces
with a connection to the sewer system.
Do not let release detergent into wa-
ters or earth.
The extraction of water from public wa-
ters is prohibited in some countries.

Proper use

This high pressure cleaner is designed for
domestic use only.
– for cleaning machines, vehicles, build-
ings, tools, facades, terraces, garden-
ing tools, etc. by means of a high-pres-
sure water jet (if necessary, with addi-
tional cleaning agents).
– with accessories, replacement parts
and cleaning agents approved by
KÄRCHER. Please observe the infor-
mation accompanying the cleaning
agents.
16 English

Description of the Appliance

The scope of delivery of the device (de-
pending on the model) is illustrated on the
packaging. These operating instructions
describe all possible options.
Illustrations on Page 2
1 Storage for spray lances
2 Storage for trigger gun
3 Transport handle, detachable
4 Carrying handle
5 Quick coupling for high pressure hose
6 Rubber band
7 Storage for high pressure hose
Storage for mains cable
8 Appliance switch „0/OFF" / „I/ON"
9 Mains cable with mains plug
10 Carrying handle
11 Nameplate
12 Bearing wheel
13 Hose coupling
14 Coupling element for water connection
15 Water connection with integrated sieve
16 Detergent suction hose (with sieve)
17 Trigger gun
18 Lock trigger gun
19 Button for detaching the high-pressure
hose from the trigger gun
20 High pressure hose
21 Spray lance with pressure regulation
(Vario Power)
Carrying out the most common cleaning
tasks.
The working pressure can be continu-
ously increased from "SOFT" to
"HARD". To adjust the working pres-
sure, release the trigger gun lever and
turn the spray lance to the desired posi-
tion.
Suitable for use with detergents.
22 Spray lance with Dirtblaster
For strong contaminations.
** Additionally required
23 Use a fabric reinforced water hose.
– Minimum diameter, 1/2 inches (13 mm).
– Minimum length 7.5 m.
