AK9834BS, AK9840BS,
AK9846BS, AK9858BS

Wiring Diagram

MOTOR
White
MOTOR
Body
REMARKS:CAPACITOR 22 μF*2 250VAC FIT AC120V 60Hz
Spruce Use, Care, and Installation Guide
Green
Yellow
Yellow
Green
Purple
Wiring Diagram
Volts Hz
120 60
White
Red
Blue
Brown
Grey
Red
Purple
Max Amps
Dual Motor 9
Black
Red
19
