AXIS Q7404 Video Encoder
How to install the product
Install the hardware
Mount the video encoder
The video encoder is supplied with a mounting kit containing screws and plugs for mounting
the video encoder to a concrete wall:
1. Place the video encoder against the wall, and mark the location of the four mounting
holes (see page 8) through which the video encoder will be attached.
2. Remove the video encoder and drill the four mounting holes.
3. Insert the wall plugs into the wall, position the video encoder, and attach it to the wall
using the screws provided.
Note
The supplied protective pads can be used to avoid scratching the surface on which the video
encoder is placed. Punch out the pads and apply them to the underside of the video encoder.
Connect the cables
1. Connect the encoder to the network using a shielded network cable.
2. Optionally connect external input/output devices, e.g. alarm devices. See page 13 for
information on the terminal connector pins.
3. Optionally connect an active speaker and/or external microphone.
4. Connect the cameras to the video inputs.
5. Connect the supplied indoor power adapter or an external power supply.
6. Check that the indicator LED:s indicate the correct conditions. See page 13 for further
details.
How to access the product
AXIS IP Utility and AXIS Camera Management are recommended methods for finding Axis products
on the network and assigning them IP addresses in Windows®. Both applications are free and can
be downloaded from axis.com/support
The product can be used with most operating systems and browsers. We recommend the following
browsers:
• Internet Explorer
®
• Safari with OS X
TM
• Chrome or Firefox
For more information about using the product, see the User Manual available at axis.com
® ®
with Windows
®
®
with other operating systems.
10
