Warning: Clamp and arm may be damaged if the lever is not tightened properly.
- Check the cooling liquid level.
- Check screws and lever, incorrectly tightening can damage the material.
- Switch on the machine.
C CLAMP OVERHAUL
The tightening of the following screws need to be inspected every month:
Screw between the arm and the clamp:
48
GYSPOT PTI S7
- Tighten the lever manually and check it is not end up
against the joint stop (see diagram below).
If it is the case go back to step previous.
These 4 screws fix the arm to the clamp. They need to be tightened to have a
good transmission of the current. A bad tightening leads to a loss of current, and
worst can damage your arm or clamp irreversibly.
