3 842 528 596 (2018-02)
TS 1 5.4
Technische Daten · Technical data · Données techniques
WT = Werkstückträger
VE = Vereinzeler
S ... = Signalgeber
Y ... = Ventil
Z ... = Zylinder
HS = Hauptstrecke
NS = Nebenstrecke
= Startimpuls nach Anlaufende
= Freigabe zyklischer Ablauf
S1 = WT in Pos. an VE 1/1 (Z 1)
S2 = WT nach VE 1/1 (Z 1)
S3 = WT in Pos. auf EQ 1
einschaltverzögert 100...200 ms
S4 = Freigabe Hauptstrecke 1
S5 = Freigabe Nebenstrecke
S6 = WT vor VE 4 (Z 4)
S7 = WT nach VE 4
S8 = WT auf EQ 2
S9 = Freigabe Hauptstrecke 2
S10 = WT vor VE 5 (Z 5)
S11 = WT nach VE 5 (Z 5)
Y1 = VE Hauptstrecke (Z 1)
Y2 = Hub-Zylinder EQ (Z 2)
Y3 = Hub-Zylinder EQ (Z 2)
Y4 = VE Nebenstrecke (Z 4)
Y5 = VE Hauptstrecke (Z 5)
Y6 = VE in EQ (Z 6)
P10 = Priorität
A1 = Geradeaussignal
WT = Workpiece pallet
VE = Stop gate
S ... = Signalling device
Y ... = Valve
Z ... = cylinder
HS = Main section
NS = Branch section
= Start pulse after end of approach
= Enable cyclical sequence
S1 = WT in position at VE 1/1 (Z 1)
S2 = WT after VE 1/1 (Z 1)
S3 = WT in position on EQ 1
switch-on delay 100 – 200 ms
S4 = Enable main section 1
S5 = Enable branch section
S6 = WT before VE 4 (Z 4)
S7 = WT after VE 4
S8 = WT on EQ 2
S9 = Enable main section 2
S10 = WT before VE 5 (Z 5)
S11 = WT after VE 5 (Z 5)
Y1 = VE main section (Z 1)
Y2 = Lift cylinder EQ (Z 2)
Y3 = Lift cylinder EQ (Z 2)
Y4 = VE branch section (Z 4)
Y5 = VE main section (Z 5)
Y6 = VE in EQ (Z 6)
P10 = Priority
A1 = Straight-ahead signal
Bosch Rexroth AG
WT = Palette porte-pièces
VE = Séparateur
S ... = Transmetteur de signal
Y ... = Valve
Z ... = Vérin
HS = Section principale
NS = Section secondaire
= Impulsion de démarrage après la fin
de l'approche
= Autorisation opération cyclique
S1 = Palette en position sur VE 1/1 (Z 1)
S2 = WT après VE1/1 (Z 1)
S3 = WT en position sur EQ 1
allumage retardé de 100 – 200 ms
S4 = Autorisation section principale 1
S5 = Autorisation section secondaire
S6 = WT avant VE 4 (Z 4)
S7 = WT après VE 4
S8 = WT sur EQ 2
S9 = Autorisation section principale 2
S10 = WT avant VE 5 (Z 5)
S11 = WT après VE 5 (Z 5)
Y1 = Section principale VE (Z 1)
Y2 = Vérin de levage EQ (Z 2)
Y3 = Vérin de levage EQ (Z 2)
Y4 = Section secondaire VE (Z 4)
Y5 = Section principale VE (Z 5)
Y6 = VE en EQ (Z 6)
P10 = Priorité
A1 = Signal directionnel
11–55
