Contrive AVIOR Manuel Utilisateur page 12

I81 RW Name
I82 UR Input status
I83 UW Running time counter
I84 RW Activation time
I85 RW Color
PULSE COUNTER INPUT 1
TAG TYPE DESCRIPTION
P10 RW Mode
P11 RW Name
P12 URW Counts accumulated ‐ total
P13 URW Counts accumulated ‐ partial during period
P14 RW Measurement period
P15 RW Measurement unit
P16 RW Pulses per count
PULSE COUNTER INPUT 2
TAG TYPE DESCRIPTION
P20 RW Mode
P21 RW Name
P22 URW Counts accumulated ‐ total
P23 URW Counts accumulated ‐ partial during period
P24 RW Measurement period
P25 RW Measurement unit
P26 RW Pulses per count
PULSE COUNTER INPUT 3
TAG TYPE DESCRIPTION
P30 RW Mode
P31 RW Name
P32 URW Counts accumulated ‐ total
P33 URW Counts accumulated ‐ partial during period
P34 RW Measurement period
P35 RW Measurement unit
P36 RW Pulses per count
PULSE COUNTER INPUT 4
TAG TYPE DESCRIPTION
P40 RW Mode
P41 RW Name
P42 URW Counts accumulated ‐ total
P43 URW Counts accumulated ‐ partial during period
P44 RW Measurement period
P45 RW Measurement unit
P46 RW Pulses per count
PULSE COUNTER INPUT 5
TAG TYPE DESCRIPTION
P50 RW Mode
P51 RW Name
P52 URW Counts accumulated ‐ total
P53 URW Counts accumulated ‐ partial during period
P54 RW Measurement period
P55 RW Measurement unit
P56 RW Pulses per count
PULSE COUNTER INPUT 6
TAG TYPE DESCRIPTION
P60 RW Mode
P61 RW Name
P62 URW Counts accumulated ‐ total
P63 URW Counts accumulated ‐ partial during period
P64 RW Measurement period
P65 RW Measurement unit
P66 RW Pulses per count
ANALOG INPUT 1
TAG TYPE DESCRIPTION
A10 RW Mode 0 = DISABLED / 1 = VOLTAGE / 2 = CURRENT / 3 = NTC
A11 RW Name
A12 URW Average measured value
A13 URW Lowest value during last period
A14 URW Highest value during last period
A15 RW Measurement period
A16 RW Measurement unit
A17 RW Value returned for FULL SCALE reading
A18 RW Value read for ZERO value
A19 URW Instant value
ANALOG INPUT 2
TAG TYPE DESCRIPTION
A20 RW Mode 0 = DISABLED / 1 = VOLTAGE / 2 = CURRENT / 3 = NTC
A21 RW Name
A22 URW Average measured value
A23 URW Lowest value during last period
A24 URW Highest value during last period
A25 RW Measurement period
A26 RW Measurement unit
A27 RW Value returned for FULL SCALE reading
A28 RW Value read for ZERO value
A29 URW Instant value
ANALOG INPUT 3
TAG TYPE DESCRIPTION
A30 RW Mode 0 = DISABLED / 1 = VOLTAGE / 2 = CURRENT / 3 = NTC
A31 RW Name
A32 UUR Average measured value
A33 URW Lowest value during last period
A34 URW Highest value during last period
A35 RW Measurement period
A36 RW Measurement unit
A37 RW Value returned for FULL SCALE reading
A38 RW Value read for ZERO value
A39 URW Instant value
ANALOG INPUT 4
TAG TYPE DESCRIPTION
A40 RW Mode 0 = DISABLED / 1 = VOLTAGE / 2 = CURRENT / 3 = NTC
A41 RW Name
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
0 = DISABLED / 1 = ENABLED
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
1 ... 100
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
4...15 ALPHANUMERIC CHAR
A42 URW Average measured value
A43 URW Lowest value during last period
A44 URW Highest value during last period
A45 RW Measurement period
A46 RW Measurement unit
A47 RW Value returned for FULL SCALE reading
A48 RW Value read for ZERO value
A49 URW Instant value
BATTERY
TAG TYPE DESCRIPTION
A50 RW Mode
A51 RW Name
A52 UR Average battery voltage
A53 UR Lowest battery voltage during last period
A54 UR Highest battery voltage during last period
A59 UR Running time counter
TEMPERATURE
TAG TYPE DESCRIPTION
A60 RW Mode
A61 RW Name
A62 UR Average temperature
A63 UR Lowest temperature during last period
A64 RW Highest temperature during last period
A65 RW Measurement period
OUTPUT 1
TAG TYPE DESCRIPTION
O10 RW Mode
O11 RW Name
O12 UR Output status
O13 UR Optional remaining time or release date
O14 RW Color
OUTPUT 2
TAG TYPE DESCRIPTION
O20 RW Mode
O21 RW Name
O22 UR Output status
O23 UR Optional remaining time or release date
O24 RW Color
OUTPUT 3
TAG TYPE DESCRIPTION
O30 RW Mode
O31 RW Name
O32 UR Output status
O33 UR Optional remaining time or release date
O34 RW Color
OUTPUT 4
TAG TYPE DESCRIPTION
O40 RW Mode
O41 RW Name
O42 UR Output status
O43 UR Optional remaining time or release date
O44 RW Color
MEMORY BIT x (1 ... F)
TAG TYPE DESCRIPTION
Mx0 RW Name
Mx1 RW Status
Mx2 UR Optional remaining time or release date
MEMORY VARIABLE x (1 ... F)
TAG TYPE DESCRIPTION
Vx0 RW Name
Vx1 UR Value
Vx2 RW Expression
1 ... 1440 MIN
UP TO 5 ALPHANUMERIC CHAR
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 999999 MIN
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
1 ... 1440 MIN
0 = DISABLED / 1 = ENABLED
0 = OFF / 1 = ON
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
OPTIONAL ‐ USED BY WEB PANEL
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
4...15 ALPHANUMERIC CHAR
1...15 ALPHANUMERIC CHAR
