MAPPING MEMOIRE – REGISTRES INTERNES
La configuration et l'état de chaque ressource de périphérique sont stockés dans le fichier de carte (D: SYSTEM /
device.map). Certains paramètres peuvent ne pas être disponibles, en fonction de la configuration de l'appareil.
Tous les paramètres peuvent être lus (type R dans le tableau ci‐dessous), la plupart d'entre eux peuvent être écrits (type
W dans le tableau ci‐dessous), certains sont actualisés périodiquement par périphérique (type U dans le tableau ci‐
dessous).
DEVICE
TAG
TYPE
DESCRIPTION
D00
R
Device type and version
D01
RW
Identifier assigned to this device (name)
D02
R
Firmware version
D03
R
Date of production
D04
R
Factory notes
D05
RW
Clock mode
D06
RW
Autoreset interval
D07
RW
Password
D08
UR
Wrong password counter
D09
RW
Input supply
D10
UR
Network in use
D11
UR
Last device IP address
D12
UR
SD card
D13
R
Device WebId
D14
UR
Current date
D15
UR
Current time
D16
UR
Weekday
D17
UR
Sunrise time
D18
UR
Sunset time
D19
UR
Last string from closed console
D20
R
Failures
WIFI
TAG
TYPE
DESCRIPTION
W00
RW
Mode
0 = OFF / 1 = ON
W01
RW
SSID
4 ... 32 ALPHANUMERIC CHARACTERS
W02
RW
Password
UP TO 64 ALPHANUMERIC CHARACTERS
W03
UR
Received Signal Strength Indicator
W04
UR
Client logged into embedded webserver
W05
UR
Local IP
GEOLOCATION
TAG
TYPE
DESCRIPTION
G00
RW
Mode
0 = MANUAL / 1 = CELL ONCE / 2 = CELL CHANGE
G01
URW
Latitude
DECIMAL DEGREES
G02
URW
Longitude
DECIMAL DEGREES
G03
URW
Range
EXPECTED POSITION RADIUS ‐ METERS
G04
URW
Nearest address
G05
URW
Language
G06
URW
Timezone
G07
URW
Offset from UTC including daylight saving time
BLUETOOTH
TAG
TYPE
DESCRIPTION
B00
RW
Mode
0 = OFF / 1 = ADVERTISER / 2 = OBSERVER
B01
RW
Advertiser ‐ UID
B02
RW
Advertiser ‐ Transmission Power Level
B03
URW
Advertiser ‐ Last message received
B04
URW
Advertiser ‐ Last message sender
B05
URW
Advertiser ‐ Group of last message received
B06
URW
Observer ‐ Min detectable signal level
B07
URW
Observer ‐ Connected user 1 (name associated to UID)
B08
URW
Observer ‐ Connected user 2 (name associated to UID)
B09
URW
Observer ‐ Connected user 3 (name associated to UID)
B10
URW
Observer ‐ Connected user 4 (name associated to UID)
INFRARED
TAG
TYPE
DESCRIPTION
F00
RW
Mode
0 = OFF / 1 = ON
F01
RW
Last received infrared code
SMM SERVER
TAG
TYPE
DESCRIPTION
S00
RW
Mode
S01
RW
Min time between connections
S02
RW
Keepalive interval
S03
RW
Server address
S04
RW
Remote Log
S05
UR
Last device sender ‐ WebId
S06
UR
Last device sender ‐ User group
S07
UR
Last device sender ‐ Received message
S08
UR
Last email sender ‐ Email address
S09
UR
Last email sender ‐ User group
S10
UR
Last email sender ‐ Received message subject
S11
UR
Last app sender ‐ APP identifier
S12
UR
Last app sender ‐ User group
S13
UR
Last app sender ‐ Received message
S14
UR
Last chat sender ‐ Phone number
S15
UR
Last chat sender ‐ User group
S16
UR
Last chat sender ‐ Received message
S17
UR
Last API text received
S18
RW
URI for map changes notification
S19
RW
URI for log changes notification
S20
RW
URI for users changes notification
S21
RW
URI for rules changes notification
PLMN
TAG
TYPE
DESCRIPTION
N00
RW
Mode
N01
RW
SIM 1 ‐ Phone number
N02
R
SIM 1 ‐ CCID
N03
RW
SIM 1 ‐ APN address
N04
RW
SIM 1 ‐ APN user name
N05
RW
SIM 1 ‐ APN password
N06
RW
SIM 2 ‐ Phone number
N07
R
SIM 2 ‐ CCID
N08
RW
SIM 2 ‐ APN address
N09
RW
SIM 2 ‐ APN user name
N10
RW
SIM 2 ‐ APN password
0 = MANUAL / 1 = AUTOMATIC
0 = NEVER / 24 ... 168 HOURS
4 TO 10 ALPHANUMERIC CHAR
0 = OFF / 1 = SUPPLY ENABLED
WiFi | 2G | 3G | 4G
0 = MISSING / 1 = DETECTED
YYMMDD ‐ YEAR MONTH DAY
hhmm ‐ HOURS MINUTES
1 = MONDAY ... 7 = SUNDAY
hhmm ‐ HOURS MINUTES
hhmm ‐ HOURS MINUTES
DEBUG STAMP
0 = OFF / 1 = ON
0 ... 10080 MIN
0 = DISABLE / 1 ... 1440 MIN
5 ... 64 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 = OFF / 1 = ON
N11
RW
Public Land Mobile Network Operator
N12
UR
Received Signal Strength Indicator
N13
UR
SIM card in use
N14
UR
PLMN module ‐ IMEI number
N15
UR
PLMN module ‐ Firmware version
N16
UR
MNC ‐ Mobile Network Code
N17
UR
MCC ‐ Mobile Country Code
N18
UR
LAC ‐ Local Area Code
N19
UR
CID ‐ Cell Identifier
N20
UR
Last incoming call ‐ Caller Phone number
N21
UR
Last incoming call ‐ DTMF received
N22
UR
Last incoming call ‐ Group of caller
N23
UR
Last received SMS ‐ Sender Phone number
N24
UR
Last received SMS ‐ Text of message
N25
UR
Last received SMS ‐ Group of last sender
N26
UR
Last originated call ‐ Recipient Phone number
N27
RW
Welcome message
N28
RW
Farewell message
LAN DEVICES
TAG
TYPE
DESCRIPTION
Y00
RW
Mode
Y01
URW
WebId of connected device in same LAN ‐ if any
Y02
URW
WebId of connected device in same LAN ‐ if any
Y03
URW
WebId of connected device in same LAN ‐ if any
Y04
URW
WebId of connected device in same LAN ‐ if any
Y05
URW
WebId of connected device in same LAN ‐ if any
Y06
URW
WebId of connected device in same LAN ‐ if any
Y07
URW
Last LAN device message ‐ Sender WebId
Y08
URW
Last LAN device message ‐ Group of sender
Y09
URW
Last LAN device message ‐ Text of message
WIEGAND
TAG
TYPE
DESCRIPTION
K00
RW
Mode
K01
URW
Last received code
K02
URW
2nd last received code
K03
URW
3rd last received code
K04
URW
4thlast received code
K05
URW
5th last received code
K06
URW
6th last received code
K07
URW
Last received code ‐ Group of sender
DIGITAL INPUT 1
TAG
TYPE
DESCRIPTION
I10
RW
Mode
I11
RW
Name
I12
UR
Input status
I13
UW
Running time counter
I14
RW
Activation time
I15
RW
Color
DIGITAL INPUT 2
TAG
TYPE
DESCRIPTION
I20
RW
Mode
I21
RW
Name
I22
UR
Input status
I23
UW
Running time counter
I24
RW
Activation time
I25
RW
Color
DIGITAL INPUT 3
TAG
TYPE
DESCRIPTION
I30
RW
Mode
I31
RW
Name
I32
UR
Input status
I33
UW
Running time counter
I34
RW
Activation time
I35
RW
Color
DIGITAL INPUT 4
TAG
TYPE
DESCRIPTION
I40
RW
Mode
I41
RW
Name
I42
UR
Input status
I43
UW
Running time counter
I44
RW
Activation time
I45
RW
Color
DIGITAL INPUT 5
TAG
TYPE
DESCRIPTION
I50
RW
Mode
I51
RW
Name
I52
UR
Input status
I53
UW
Running time counter
I54
RW
Activation time
I55
RW
Color
DIGITAL INPUT 6
TAG
TYPE
DESCRIPTION
I60
RW
Mode
I61
RW
Name
I62
UR
Input status
I63
UW
Running time counter
I64
RW
Activation time
I65
RW
Color
MAIN POWER SUPPLY
TAG
TYPE
DESCRIPTION
I70
RW
Mode
I71
RW
Name
I72
UR
Input status
I73
UW
Running time counter
I74
RW
Activation time
I75
RW
Color
AUX POWER SUPPLY
TAG
TYPE
DESCRIPTION
I80
RW
Mode
0 = OFF / 1 = ON
0 = OFF / 1 = ON
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
4...15 ALPHANUMERIC CHAR
0 = OFF / 1 = ON
0 ... 999999 MIN
0 = IMMEDIATE / 1 ... 65535 SEC
OPTIONAL ‐ USED BY WEB PANEL
0 = DISABLED / 1 = ENABLED
