Clip the anchor attachments directly onto the vehicle anchorage points (or lower anchor straps
13b
if you have used them). Press down hard on the top of one side (i) of the child restraint then
repeat on the other side (ii). When you do this it' s important that you really use your full body
weight to press down and get the tether straps to really tighten hard. This will give the tether straps
their first tightening.
Unfold the support leg (R) out to its maximum angle. Pull out the top latch (S) to release the
14b
upper part of the support leg until it reaches the floor. If the support leg does not reach the floor,
repeat with the lower latch (T).
It is important that you check that the support leg is at an angle over 10° from the back of the
15b
seat. You could check this by ensuring that the support leg is further away from the seat than
the vertical line.
Press down on the child restraint from side to side again (i)(ii), the tether straps will be then be
16b
automatically tightened.
If you have installed Rekid in the back seat you can now move the front seat to a comfortable position.
Note: The back of the child restraint may, but does not need to be in contact with the back of the front
seat.
Placing Your Child In The Seat
Press the harness adjuster button (E) and pull forward on the shoulder straps (not the shoulder pads)
17
to completely loosen the harness.
18
Press the red harness release button on the buckle and unfasten the harness.
Place your child in the car seat. Put your child' s arms in between the shoulder straps so that the
19
straps are hanging over the chest and stomach.
20
Pull the shoulder straps together and insert the harness tongues into the crotch buckle.
Pull the harness adjustment strap (F). It' s important that you always pull the harness straight
21
and central when you tighten the adjustment strap. This will tighten the harness and the
headrest will automatically slide down to the appropriate height.
10
