2.1 TABLE OF WEIGHTS AND MEASURES
DIMENSIONS
MODEL
CHEF 600 MN 53x24x44
CHEF 600 TR 53x24x44
CHEF 800 MN 56x24x50
CHEF 800 TR 56x24x50
Noise "CHEF 600-800" N. 67 DB"
Warning: the electrical features of each equipment are printed on the motor data plate a check of the
electric connection is necessary before installing the equipment.

2.2 SUPPLY CONDITIONS AND DISPOSAL OF PACKINGS

All the cutting machines are packed in a sturdy cardboard box with internal shaped edges which guarantee
the perfect integrity of the machine during transport.
Each equipment include:
• Declaration of conformity E.E.C.
• Instructions for use and maintenance
• Ejecting disc.
ALL THE PACKING COMPONENTS (CARTON, FOAM, STRAPS, AND SO ON) CAN
EASILY BE DISPOSED OF AS HOUSEHOLD RUBBISH.
WHENEVER THE MACHINE IS INSTALLED IN COUNTRIES HAVING SPECIAL
REGULATIONS ON PACKING DISPOSAL, THE FINAL USER MUST COMPLY WITH
THE REGULATIONS IN FORCE.
THE USE OF THE WEEE SYMBOL INDICATES THAT THIS PRODUCT MAY NOT BE
TREATED AS HOUSEHOLD WASTE. BY ENSURING THIS PRODUCT IS DISPOSED OF
CORRECTLY, YOU WILL HELP PROTECT THE ENVIRONMENT. FOR MORE
DETAILED INFORMATION ABOUT THE RECYCLING OF THIS PRODUCT, PLEASE
CONTACT YOUR LOCAL AUTHORITY, YOUR HOUSEHOLD WASTE DISPOSAL
SERVICE PROVIDER OR THE SHOP WHERE YOU PURCHASED THE PRODUCT.

3.1 SETTING THE MACHINE

The machine connection and the setting at work must be made by skilled personnel.
Warning: both the system and location where the equipment has to be set must comply with the regulations
for the accident prevention and electrical regulation CEI in force.
The manufacturer declines any and all responsibility for direct or indirect damages which may ensue
for non-compliance with the above mentioned regulations.
Set the equipment on a wide, levelled, dry and fixed face, ,far from heat sources and water sprays.

3.2 ELECTRIC CONNECTIONS

The equipment is supplied with an electric cable to be connected to a magneto-thermic main switch which
stops the machine when the operator comes in fortuitous contact with the rotating elements.
It is imperative that the equipment is well grounded according to the regulations in force.
The manufacturer declines any and all responsibility for direct and indirect damages which may
ensue for non-compliance with the regulations in force.
All the cutting machines of the series "CHEF" are manufactured into two versions: three-phase V.400/3/50
HZ, or single-phase V.230/1/50 HZ.
Whenever the voltage differs from the above mentioned ones, please apply to the manufacturer, or the
authorized distributor. (See figures 2 and 3)
WEIGHT
CM. KG.
19
19
20
20

3) INSTALLATION

POWER ELECTRICAL
WATT CONNECTION
380 230x50x1
400 400x50x3
550 230x50x1
600 400x50x3
REVS
DISC
Nr.280
Nr.280
Nr.310
Nr.310
10
