Bottom View - Blue Wave RX600 Manuel De L'utilisateur

3. Slowly insert the Motor back into the Canister. There's a groove on the bottom of the Motor (marked "ALIGN"). Make sure that the groove aligns with notch on the
Canister (only visible from bottom), otherwise the Pump Base may leak even already locked in place.
Also, the Rubble Nozzle should be aligned with the Canister's water outlet.
o
BOTTOM VIEW
19
4. Once the Motor is correctly aligned, and the Canister Gasket is in place, match the threads of the Pump Base to that of the Canister, and tighten by twisting the
Base clockwise.
IMPORTANT: make sure that the Base and Canister are not cross-threaded; otherwise leaks may occur.
16
The arrow of the "ALIGN" marker should
point to the notch of the Canister.
17
Step 4
15
19
17
Step 3
Make sure that the notch and groove are aligned.
18
Make sure that the Rubber Nozzle
is aligned with the Canister outlet.
17
TOP VIEW
17
19
o
15
19
