Yakima EXO LitKit Instructions De Montage page 2

1
ATTACH THE LIGHT TUBES TO THE LIGHTS.
Pass the connector through the center hole of the left light tube as
provided 10 mm wrench to assemble the left and right side lights to the left and
right side light tubes as shown using 2 bolts, 2 washers, and 2 nuts for each side.
2
EXTEND THE EXO SWINGBASE™ ARMS.
To extend the arms, first pull the pin on the driver-side arm and swing it out until
it locks into place. Then, pull the pin on the passenger-side arm and swing it out
until it locks into place. NOTE: The EXO LitKit is not intended to remain installed
when the EXO SwingBase arms are folded back to their stowed positions.
Instruction #1036058B - page 2 of 10
ASSEMBLY
CAUTION: Keep your fingers away from ALL moving parts!
shown. Use the
