FIGURE 1
SPEAKER PLACEMENT
TWO CHANNEL
6'-15'
L
6'-15'
Angle inward
*
Less distance will increase bass,
but worsen sound quality.
FIGURE 3
PLACEMENT OF CENTER
CHANNEL SPEAKER ON TV
Top
TV
Below
FIGURE 5
SPEAKER WIRE HOOK UP
BI-WIRE
AMP
Left Speaker
(remove strap)
All power off!
Observe polarity (+ to +, and - to -).
*
2'- 3'
R
Tilt foot
Right Speaker
(remove strap)
FIGURE 2
S
6'-15'
TV
Optional
sub
C
L
Y
X
B
Optional
rear placement
A is ideal. B or combo A, B is acceptable.
FIGURE 4
SPEAKER WIRE HOOK UP
STANDARD
AMP
Left Speaker
(leave strap)
All power off!
Observe polarity (+ to +, and - to -).
Don't leave excess bare wire
(strip about 1/4" at ends)
or wire touching (+ to-).
FIGURE 6
Don't create trip hazard!
SPEAKER WIRE HOOK UP
STANDARD
AMP
Left Speaker
All power off!
Observe polarity (+ to +, and - to -).
S
Optional
sub
R
X=Y=Z
Z
B
Right Speaker
(leave strap)
Right Speaker
loading
