4.2.2
Function Name
FUNCTION NAME
Store
"LibStr__"
Recall
"LibRcl__"
Unknown Factor Store
"LibUnStr"
Unknown Factor Recall
"LibUnRcl"
Store Undo (only Scene)
"LibStrUd"
Recall Undo (only Scene)
"LibRclUd"
4.2.3
Module Name
MODULE NAME
Scene
"SCENE___"
Input CH
"INCHNNL_"
Output CH
"OUTCHNNL"
Input EQ
"INEQ____"
Output EQ
"OUTEQ___"
Dynamics
"DYNA____"
GEQ
"GEQ_____"
Effect
"EFFECT__"
Function
Number
"LibStr__"
SCENE
1- 300
INPUT CH LIB
1-199
OUTPUT CH LIB
1-199
INPUT EQ LIB
41- 199
OUTPUT EQ LIB
4- 199
Dynamics LIB
42- 199
GEQ LIB
1- 199
EFFECT LIB
58- 199
"LibUnStr"
SCENE
1- 300
INPUT CH LIB
1-199
OUTPUT CH LIB
1-199
INPUT EQ LIB
41- 199
OUTPUT EQ LIB
4- 199
Dynamics LIB
42- 199
GEQ LIB
1- 199
EFFECT LIB
58- 199
"LibRcl__"
SCENE
0- 300
INPUT CH LIB
0-199
OUTPUT CH LIB
0-199
INPUT EQ LIB
1- 199
OUTPUT EQ LIB
1- 199
Dynamics LIB
1- 199
GEQ LIB
0- 199
EFFECT LIB
1- 199
"LibUnRcl"
SCENE
0
INPUT CH LIB
0
OUTPUT CH LIB
0
INPUT EQ LIB
0
OUTPUT EQ LIB
0
Dynamics LIB
0
GEQ LIB
0
EFFECT LIB
0
"LibStrUd"
SCENE
0
"LibRclUd"
SCENE
0
*1) 0:CH1–47:CH48
48:ST IN 1L–55:ST IN 4R
*2) 256:MIX1–271:MIX16
*3) 512:MATRIX1–519:MATRIX8
*4) 1024:STEREO L–1026:MONO(C)
*5) 512:will be used if the recalling or storing data is only one.
*6) 0:RACK1–7:RACK8 If a GEQ is mounted in RACK 1–8.
*7) 0:RACK5–3:RACK8 If an effect is mounted in RACK 5–8.
*8) 1280:CH 1–1327:CH 48
1328:STIN 1L–1335:STIN 4R
(Dynamics2)
channel*1)
tx/rx
*5)
tx/rx
*1)
tx/rx
*2) *3) *4)
tx/rx
*1)
tx/rx
*2) *3) *4)
tx/rx
*1) *2) *3) *4) *8)
tx/rx
*6)
tx/rx
*7)
tx/rx
0
tx
0
tx
0
tx
0
tx
0
tx
0
tx
0
tx
0
tx
*5)
tx/rx
*1)
tx/rx
*2) *3) *4)
tx/rx
*1)
tx/rx
*2) *3) *4)
tx/rx
*1) *2) *3) *4) *8)
tx/rx
*6)
tx/rx
*7)
tx/rx
*5)
tx
*1)
tx
*2) *3) *4)
tx
*1)
tx
*2) *3) *4)
tx
*1) *2) *3) *4) *8)
tx
*6)
tx
*7)
tx
0
0
4.3 Function call – library edit –
4.3.1
Format (Parameter change)
Receive
Data will be received when [Parameter change Rx] is on and the Device number
of both [Rx CH] and SUB STATUS are matched. The data will be echoed when
[Parameter change ECHO] is on. The corresponding memory/library will be
changed immediately the data is received.
Transmission
Parameter Change Message will be sent in reply to Request. If [Parameter change
ECHO] is on, the message will be sent as it is.
System exclusive message
STATUS
11110000 F0
Manufacture's ID number (YAMAHA)
ID No.
01000011 43
n=0-15 (Device number=MIDI Channel)
SUB STATUS 0001nnnn 1n
Digital mixer
GROUP ID
00111110 3E
M7CL
MODEL ID
00010001 11
OTHER DATA
DATA
00000000 00
CATEGORY
(ASCII CODE)
FUNCTION
01001100 "L"
NAME
(ASCII CODE)
01101001 "i"
(ASCII CODE)
01100010 "b"
(ASCII CODE)
0fffffff ff
(ASCII CODE)
0fffffff ff
(ASCII CODE)
0fffffff ff
(ASCII CODE)
0fffffff ff
(ASCII CODE)
0fffffff ff
(ASCII CODE)
MODULE NAME 0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
(ASCII CODE)
0mmmmmmm mm
number -source start High
DATA
0mmmmmmm mh
number -source start Low
0mmmmmmm ml
number -source end High
0mmmmmmm mh
number -source end Low
0mmmmmmm ml
number -destination start High
0mmmmmmm mh
number -destination to start Low
0mmmmmmm ml
End of exclusive
EOX
11110111 F7
4.3.2
Function Name
FUNCTION NAME
Copy
"LibCpy__"
Paste
"LibPst__"
Clear
"LibClr__"
Cut
"LibCut__"
Insert
"LibIns__"
Edit Undo
"LibEdtUd"
4.3.3
Module Name
MODULE NAME
SCENE LIB
"SCENE___"
INPUT CH LIB
"INCHNNL_"
OUTPUT CH LIB
"OUTCHNNL"
INPUT EQ LIB
"INEQ____"
OUTPUT EQ LIB
"OUTEQ___"
Dynamics LIB
"DYNA____"
GEQ LIB
"GEQ_____"
EFFECT LIB
"EFFECT__"
