Selve SE Plus-RC Mode D'emploi page 57

commeo initial operation/Setting by radio
Configuration using a transmitter without display
The status LED starts flashing green or red slowly. The transmitter shows the first bit.
The first bit is displayed by one flash. Use the UP button to set the first bit to 1 (green
status LED) and the DOWN button to set it to 0 (red status LED). Pushing the STOP
button calls the next bit. The status LED shows the second bit; the status LED flashes
green or red 2 x in sequence. Every push of the STOP button jumps forward one bit.
The bit can be set as described above. The frequency of flashing corresponds to the
bit position.
After setting the last bit, pushing the STOP button leaves the CONFIGURATION mode.
The status LED starts flashing orange. The transmitter is in SELECT mode.
Operation
+
3 s
1 s
1 s
1 s
Configuration using commeo Multi Send
Operation is the same as for transmitters without a display. The status LED con tinues
to flash orange. The display shows the bit screen for the receiver. Save the setting using
the display button on the right (Enter button symbol).
SE Plus-RC
Sample image for commeo Multi Send display
Status LED Setting
green = 1
= green = 1
1 x
red = 0 = red = 0
green = 1
= green = 1
2 x
red = 0 = red = 0
green = 1
= green = 1
3 x
red = 0 = red = 0
orange
ID of receiver (not susceptible)
commeo Multi Send bitmask
