Virax V150+ Manuel D'instructions page 16

050111 & 050121 for
Support stands
Dimensions
Support length
Weight
Maximum core bit
diameter
Tilt angle
Brake lever
Position lock
Motor attachment
Position
Function with Virax core
drills
Accessories available
Description
Set of
attachments
Slot cap
Vacuum pump
Vacuum clamp
base seal
Water collector
Seal for collector
Anti-lock washer
Set of 2 wheels
The support stands are delivered with:
-
1 SW 6 wrench and 1 SW 8 wrench,
-
1 set of attachments (ref. Virax 050141)
- 1 brake lever
- 1 tightening lever for core drill (support stand 050111 only)
- 4 M8 x 20 screws for attachment plate for core drill (support stand 050121
only)
I – Technical data
380 x 250 x 1200 mm
Quick by prism
Ref. 050110
(Support stand
050111 + Core drill
050116)
050114
050115
050112
050113
050119
core drills
VIRAX
050111
1000 mm
13 kg
160 mm
0° to 45°
Yes
Yes
4 positioning screws and 2 levels
050116
Ref. 050120
(Support stand
050121 + Core drill
050126)
050141
050043
050122
050123
050139
Delivered as standard
16
050121
520 x 330 x 1100 mm
20.5 kg
350 mm
By plate screwing
050126 and 050136
Ref. 050130
(Support stand
050121 + Core drill
050136)
050124
050125
050132
050133
-EN-
