POWERING UP THE PROGRAM BOX

A charged battery, connected to the ESC is required as
power source. Once the ESC is connected to the program
box, switch on the ESC and the program box will also power
on. Information is displayed in the following order.
1. Program box firmware version.
2. ESC firmware version
3. Current setting profiles memory (0, 1 or 2)
4. Parameters display

ESC SETTING PROFILES MEMORY

Some ESC allow you to memorize three different setting
profiles. Thanks to this, you can select a different profile
to make experimentations and not have to modify a set of
settings which already works adequately.
To change the profile:
1. After the startup procedure is complete, press the
"profile" key.
2. Press the "value" key to switch profile (0, 1 or 2).
3. The settings are automatically loaded.

MODIFYING THE PARAMETERS

Follow this procedure to modify the parameters:
1. Wait for the power up procedure to complete
2. Press the "item" key to switch between the different
parameters.
3. Press the "value" key to change the setting of the current
parameter.
