list des pièces

MAIN ASSEMBLY

Part # Description
1) 076-201 Cast Stove Top
2) 076-211 Cast Pedestal
3) 156-524 Surround Door
4) 156-513 Curved Door
5) 156-261 Thin Surround
6) 076-921 Side Shield (Black Set)
076-927 Side Shield (Stainless)
7) 156-519 Door Catch Assembly
8) 076-516 Heat Shield
9) 156-523 Door Hinge Assembly
10) 942-110 Ash drawer plug
11) 076-911 Ash Drawer Assembly
12) 076-004 Fan Opening Cover
13) 076-010 Back Shield
14) 074-954 Air tube
15) 033-953 Air tube
16) 073-955 Baffle set
17) 076-022 Ashlip
16
14
15
5
7
4
2
30 | Regency CS1200
10
11 14
3 9
Part # Description
076-512 Firebox Assembly
940-366/P Neoceram Glass
918-896 Manual
1
6
8
12
13
17
